Digital Watchdog MEGApix DWC-MVA5Wi28T User Manual page 71

Specification
CAMERA
Image sensor 1/2.8" 2.1MP/1080p CMOS
Total pixels 1945 (H) X 1109 (V)
2.8mm, F2.0
Focal length
Field angle
D: 127°, H: 110°, V: 59°
Auto / manual (1/15 ~ 1/32000),
anti-flicker, slow shutter (1/2｜1/3｜1/5
Shutter speed
1/6｜1/7.5｜1/10)
MIN. illumination 0.05 lux (color), 0 lux with IR (F2.0)
IR H2IR, 80ft
WDR True WDR (DOL)
Day and night TDN (true day and night)
DNR 3D-DNR
Privacy zone 16 programmable zone
AGC Auto
Exposure, white balance, sharpness, BLC,
Other image processing
brightness, contrast, saturation, hue
ENCODER (VIDEO AND AUDIO)
Video Compression H.265, H.264, MJPEG
H.264 profile MP/HP
H.265 profile MP
Multiple profile
1080p @30fps + D1 (704x480 or 704x576)
streaming
@30fps with H.264, H.265 + MJPEG
performance
100kbps~10Mbps, multi-rate for
Video bitrate
preview and recording
Multistreaming CBR/VBR at H.264,
H.265 (controllable frame rate and
Bitrate control
bandwidth)
Event notification FTP, E-mail
SECURITY AND NETWORK
Network protocol
Security
Plug-in
GENERAL
Support languages
Power
Temperature
Material
Dimensions (DXH)
Weight
Certification
71
IPv4:
TCP/IP / UDP / AutoIP / RTP(UDP/TCP)
/ RTSP / NTP / HTTP / HTTPS / SSL / DNS
/ DDNS / DHCP / FTP / SMTP / ICMP /
SNMPv1/v2/v3(MIB-2) / ONVIF
HTTPS (SSL), IP filtering, 802.1x,
Digest Authentication
CGI, API, ONVIF
English
(Adaptor is not Included)
DC12V: max 5.7W
POE IEEE 802.3af Class3: max 7.2W
-4°F ~ 122°F (-20°C ~ 50°C)
Aluminum die-casting
4.92" x 4.8" (125 x 122 mm)
1.76lbs (0.8kg)
FCC, CE, ROHS, IP67, IK10
