Angler Quick-Open Deep Parabolic Softbox V2 Instructions Manual page 4

Using the Diffusers
The inner and outer diffusers soften and spread the beam for an even and flattering
wraparound light.
Note: Each diffuser will reduce the light output by approx. 1 stop.
Attaching the Inner Diffuser
The inner diffuser is the smaller of the two and has
snap fasteners around its edge. Attach each of the
snaps to the ones on the softbox interior until the
diffuser is taut.
Attaching the Outer Diffuser
Attach the outer diffuser by pressing the touch-
connect strip against the inner rim of the softbox.
Note: If you plan on using the accessory grid (sold
seperately), attach the diffuser to the inner half of
the touch-connect strip to leave enough room for
the grid.
Closing the Softbox
1. Open the vents, and remove the softbox from
the Bowens mount of your monolight.
2. Place the softbox facedown on a flat surface.
3.
Lift up on each support rod while pressing the
adjacent release lever. The support rods will fold
down.
