- Page 1 14 in. LED Bi-color Ring Light and Light Stand BI-45W-RL INSTRUCTIONS...
- Page 2 Thank you for choosing Angler. The Angler BI-45W-RL is a 14-inch ring light that’s ideal for lighting vlogs and interviews, and self-lighting influencer videos and home broadcasts. Its bi-color SMD LEDs are housed in a diffuser that softens and spreads the beam for a flattering single-shadow light that’s bright and color accurate.
- Page 3 Failure to observe this pre- caution could result in electric shock or product malfunction. This will void the warranty, and Angler will not be responsible for any damage. Use only the correct, recommended voltage. Make sure the unit is powered off when plugging it into a power source.
- Page 4 Overview LED array LED screen (front) (under diffuser) Brightness display Power/Brightness knob Tilt lock Color Temperature knob 5/8 in. receiver...
- Page 5 Keyhole suspension USB charging port slot NP-F battery Heat vents contacts 1/4-20 accessory Battery release socket button Shoe mount LED screen (back) AC power socket Locking knob...
- Page 6 Phone Clamp Phone clamp Flexible arm Locking wheel Light Stand 5/8 in. pin LED Screen (back) Locking knobs Battery display Leg lock Color temperature display...
-
Page 7: Remote Control
Remote Control Power button Daylight button Brightness up Save button Color temp up Color temp down Brightness Auto down buttons (100%) Auto buttons (50%) Also included: AC adapter Power cord Carry bag... - Page 8 Setting Up the Light Stand Loosen the leg lock, and unfold the legs to the desired angle. Tighten the leg lock until secure. Important! Set the legs at a wide enough angle to ensure stability of the ring light and attached camera or accessories. Loosen the center column locking knobs and adjust the stand to the desired height.
- Page 9 Mounting the BI-45W-RL Loosen the locking knob, and place the receiver onto the light stand’s 5/8-inch pin. Make sure the receiver fits completely over the pin before you tighten the locking knob. If it doesn’t, continue to loosen the locking knob until the fixture drops down around the pin.
- Page 10 Powering On the Light AC Power When operating the light on AC power, remove the batteries. Plug the power adapter into the light, and plug the power cord into an available outlet. OFF will appear on the control screen to indicate the light is receiving power.
- Page 11 Battery Power A 7.4 V NP-F type battery is recommended for the BI-45W-RL ring light. When operating the light on battery power, unplug the power adapter from the light. Place an NP-F battery into the battery plate, and slide it toward the contacts until locked in place.
- Page 12 Adjusting the Color Temperature and Brightness Color Temperature Turn the color temperature knob to adjust the color temperature from 2700 to 5600 K in 100 K increments. Brightness Turn the dimmer knob to adjust the output level from 0% to 100% in 1% increments.
-
Page 13: Using The Memory Function
Using the Memory Function When you power on the light, it will resume operation with the color temperature and brightness that are set in the memory. To set the memory function, follow these steps. Color Temperature Turn the color temperature knob to set the color temperature. Press and hold the color temperature knob until the color temperature display blinks. -
Page 14: Adding Accessories
Attaching a Smartphone Insert the phone into the spring-loaded clamp. Attach the flex arm smartphone holder to the shoe mount by sliding it into the shoe and tightening the locking wheel. 3. Loosen the locking knob at the base of the phone clamp, and adjust the phone’s orientation. -
Page 15: Remote Operation
Remote Operation The included remote uses an infrared beam to operate the ring light. For remote operation, line of sight is required, and the maximum range is approximately 50 feet. Power Button Press the power button to turn on the ring light. - Page 16 Brightness Up/Down The brightness control lets you adjust the light’s brightness from 0% to 100% in 1% increments. Color Temperature Control The color temperature control adjusts the color temperature from 2700 to 5600 K in 100 K increments. Save Button To save the current brightness and color temperature, press and hold the save button until the display blinks.
- Page 17 Recycling Lithium-Ion Batteries Lithium-ion batteries are recyclable. You can help preserve the environment by returning your used rechargeable batteries to a collection and recycling location near you. For more information about recycling rechargeable batteries, call the Call2Recycle helpline at 1-877-723-1297, or visit www.call2recycle.org.
-
Page 18: Specifications
Specifications LIGHT FIXTURE LED Chip Type Color Temperature 2700 to 5600 K Color Accuracy CRI: 98 (3200 K) / 96 (4400 K) / 98 (5600 K) Standard TLCI: 98 (3200 K) / 98 (4400 K) / 98 (5600 K) Cooling System Passive Yes, 0% to 100% Dimming... - Page 19 MOUNTING 5/8 in. Fixture Mount +/– 90° Tilt CONNECTORS Battery Plate NP-F Power INPUT bARREL CONNECTOR Power Output USB Standard-A Connector Remote Operation Remote Control Proprietary Type Frequency POWER AC Input Power 100 to 240 V AC, 50/60 Hz DC Input Power 7.4 V DC Power Source AC adapter, NP-F battery...
-
Page 20: One-Year Limited Warranty
One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
