Angler Sparta Series Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Sparta Series
865BLED
INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sparta Series and is the answer not in the manual?

Questions and answers

Related Manuals for Angler Sparta Series

Summary of Contents for Angler Sparta Series

  • Page 1 Sparta Series 865BLED INSTRUCTIONS...
  • Page 2 Thank you for choosing Angler. The 865BLED from Angler’s Sparta Series is a slim, lightweight, and powerful LED fixture that will add versatility to your set. This fixture is ideal for head shots, portraits, and interviews on small sets due to its color accuracy and precise brightness and color temperature control.
  • Page 3 Do not attempt to disassemble or repair the equipment. There are high-voltage components inside the unit. Failure to observe this precaution could result in electric shock or product malfunction. This will void the warranty, and Angler will not be responsible for any damage. Use only the correct, recommended voltage.
  • Page 4 Overview Barndoors Accessory slots Locking array Two-way 5/8 inch Yoke receiver Diffuser Locking knob...
  • Page 5 Power display input Tab release Tilt locks buttons Battery plates Channel select button Power button Adjustment knob Check battery button Also included: AC power cord AC power adapter and cord Travel Case...

  • Page 6: Powering On The Light

    Mounting the 865BLED Make sure the tilt locks are securely tightened before mounting the fixture. Loosen the locking knob, and mount the receiver vertically or horizontally onto a light stand with a 5/8 in. baby pin. 3. Tighten the locking knob until secure. 4.
  • Page 7 Battery Power When operating on battery power, unplug the power adapter from the AC outlet and from the light. Place two NP-F batteries into the battery plates, and slide them toward the contacts until the battery is firmly in place. Press and hold the power button until the light comes on.
  • Page 8 Adjusting the Brightness Press the adjustment dial so the LED appears under Dimmer. Select the output level from 10 to 99. Wireless Operation The brightness and color temperature settings can be controlled remotely from up to 100 feet away with the Genaray MB-WRT Wireless Remote (sold separately).
  • Page 9 Diffuser and Barndoors Removing the Barndoors and Diffuser Move either one of the tab release buttons and lower the locking tab. Slide the barndoors and/or the diffuser off the accessory rails. To replace the Barndoors and Diffuser Raise one of the locking tabs to its locked position.

  • Page 10: Specifications

    Specifications LIGHT FIXTURE SMD LED LED Chip Type Output Power 36 W Beam Angle 60° Color Temperature 3200 to 5600 K Color Accuracy CRI 94.6 TLCI 96.5 Standard None Cooling System Yes, 10% - 100% in 1% increments Dimming Display Housing Material Metal 3200 K: 2609 lx @ 3 ft.
  • Page 11 MOUNTING Fixture Mount Two-way 5/8 in. receiver YOKE Yoke Material Metal Yoke/Bracket Yoke Type 360° Tilt Remote Operation Remote Control 2.4 GHz Type Number of Channels 100 ft. (30 m) Wireless Range POWER AC Input Power 100 to 240 V AC, 50/60 Hz 13 to 19 V DC DC Input Power Power Adapter...

  • Page 12: One-Year Limited Warranty

    One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.

This manual is also suitable for:

865bled
