Angler RLB18LED Instructions Manual

Bi-color ringlight (18 in.)
Hide thumbs

Advertisement

Quick Links

Download this manual
Bi-Color Ringlight (18 in.)
RLB18LED
INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the RLB18LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Angler RLB18LED

Summary of Contents for Angler RLB18LED

  • Page 1 Bi-Color Ringlight (18 in.) RLB18LED INSTRUCTIONS...
  • Page 2 Thank you for choosing Angler. Angler’s 18-inch bi-color Ringlight is ideal for photographers and videographers who need a warm, diffuse and near-shadowless light with a wide beam spread to illuminate their subjects. The 18-inch Ringlight is also perfect for personal and professional makeup and cosmetics applications, and for lighting selfies and vlogs.
  • Page 3 Do not attempt to disassemble or repair the equipment. There are high-voltage components inside the unit. Failure to observe this precaution could result in electric shock or product malfunction. This will void the warranty, and Angler will not be responsible for any damage. Use only the correct, recommended voltage.
  • Page 4 Overview LED array under diffuser 1/4-20 socket 1/4-20 screw Locking wheel Locking knob Tilt lock Mounting Handle...
  • Page 5 NP-F battery slots Shoe mounts Dimmer Power input Power switch Battery check Color temperature knob button LCD screen 5/8 in. receiver...
  • Page 6 1/4-20 mounting bolt Mini Ballhead Locking wheel Shoe lock Shoe mount Ball tension screw Adjustment Smartphone Bracket clamp Tilt lock 1/4-20 socket...
  • Page 7 Mirror Locking wheel Shoe mount Also Included: AC power cord AC power adapter and cord Travel case...
  • Page 8 Mounting the Ringlight Light Stand To mount the Ringlight on a light stand, loosen the mounting handle’s locking knob, and place the receiver over the light stand’s 5/8-inch pin. Make sure the receiver fits complete- ly around the pin before you tighten the locking knob.

  • Page 9: Powering On The Light

    Powering On the Light AC Power When operating on AC power, first remove the batteries. Plug the power adapter into the light, and plug the power cord into an available outlet. Move the power switch to ON. Battery Power When operating on battery power, unplug the power adapter from the AC outlet and from the light.
  • Page 10 Adjusting the Color Temperature and Brightness Color Temperature Turn the color temperature knob to adjust the color temperature from 3200 K (tungsten balance) to 5600 K (daylight balance). Brightness Turn the dimmer knob to adjust the output level from 0% to 100% in 1% increments.
  • Page 11 Using the Ringlight with a Camera Attaching a camera in the center of the Ringlight is an ideal way to shoot cosmetics and fashion. To mount a camera to the Ringlight, follow these steps: Loosen the mini ballhead’s locking wheel by turning it counterclockwise. Screw the mini ballhead into the threaded mounting socket on the camera, and tighten the locking wheel...
  • Page 12 Using the Ringlight with a Smartphone Loosen the mini ballhead’s locking wheel by turning it counterclockwise . Screw the mini ballhead into the threaded mounting socket on the smartphone bracket, and tighten the locking wheel by turning it clockwise until snug. 3.
  • Page 13 Using the Mirror Use the mirror to let your subject check their hair and makeup in front of the light. To attach the mirror to the Ringlight, follow these steps: Loosen the locking wheel by turning it counterclockwise. Slide the mirror into either one of the Ringlight’s shoe mounts.

  • Page 14: Specifications

    Specifications LIGHT FIXTURE SMD LED LED Chip Type 120° Beam Angle 3200 to 5600 K Color Temperature CRI 96.6 (5600 K) / 96.7 (4400 K) / 98.5 (3200 K) Color Accuracy Standard TLCI 95.2 (5600 K) / 97.7 (4400 K) / 98.6 (3200 K) Cooling System Passive Dimming...
  • Page 15 Mounting 5/8 in. receiver Fixture Mount 1/4-20 threaded socket Cold-shoe mount (×2) Mount Smartphone bracket with 1/4-20 threaded socket POWER AC Input Power 100 to 240 V AC, 50/60 Hz DC Input Power 15 to 16.8 V DC Power Adapter 15 V, 4.0 A DC Power Source AC adapter, NP-F battery (×2)

  • Page 16: One-Year Limited Warranty

    One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
