5.6. External communication interface
5.6.1 USB/WIFI communication interface
Fig.5-5 USB/WIFI communication interface
Table5-6 Interface description
USB
communication
interface
5.6.2 DRMs interface- Logic interface
Fig.5-6 Logic interface
HYD 5-20KTL-3PH
④
①
USB ： USB flash disk
access
WIFI ： WIFI data
collector access
1.White and orange
2.Orange
3.White and green
4.Blue
5.White and blue
6.Green
7.White and brown
8.Brown
①
Copyright ©Shenzhen SOFARSOLAR Co., Ltd
⑤
②
Used for inverter firmware
upgrade and data recording
Used to connect WiFi data
collector
②
- 35 -
User manual
⑥
③
③
