Display mode II:
This display mode makes it possible to have
three operating data values displayed at the
same time in line 1.
The operating data values are determined in
parameters 007-010 Display readout.
100% 7,8A 5,9KW
50.0Hz
AUTO REMOTE RUNNING
Display mode III:
This display mode can be generated as long
as the [DISPLAY MODE] key is kept
depressed. In the first line, operating data
names and units of operating data are
displayed. In the second line, operating data 2
remains unchanged. When the key is
released, the different operating data values
are shown.
REF% CURR.A
50.0Hz
AUTO REMOTE RUNNING
MG.60.C4.02 – VLT is a registered Danfoss trademark
®
VLT 6000 HVAC
Display mode IV:
This display mode is only generated in
connection with local reference.
In this display mode, the reference is
determined via the [+/-] keys and control is
carried out by means of the keys underneath
the indicator lamps.
The first line indicates the required reference.
The third line gives the relative value of the
present output frequency at any given time in
relation to the maximum frequency. The display
SETUP
is in the form of a bar graph.
1
USE +/-
0
AUTO REMOTE
SETUP
1
40Hz
SETUP
1
----- 60
