Danfoss VLT 6000 Quick Setup Manual page 15

Electrical installation, control cables
Max. control cable cross-section: 1.5 mm
AWG
Torque: 0.5-0.6 Nm
Screw size: M3
See Earthing of screened/armoured control
cables for correct termination of control cables.
No. Function
Relay output 1 can be used for
04, 05
indicating status and warnings.
Voltage supply to digital inputs.
12, 13
For the 24 V DC to be used for
digital inputs, switch 4 on the
control card must be closed,
position "on".
Digital inputs. See parameters
16-33
300-307 Digital inputs.
20
Ground for digital inputs.
39 Ground for analogue/digital
outputs. Must be connnected
to terminal 55 by means of a
three-wire transmitter.
Analogue/digital outputs for
42, 45
indicating frequency, reference,
current and torque. See
parameters 319-322 Analogue/
digital outputs.
Supply voltage to
50
potentiometer and thermistor
10 V DC.
14
VLT ® 6000 HVAC
Analogue voltage input, 0 - 10 V
53, 54
2
/16 DC.
Ground for analogue voltage
55
inputs.
Analogue current input 0/4-20
60
mA.
See parameters 314-316
Terminal 60.
61
Termination of serial
communication. See Earthing of
screened/armoured control
cables.
This terminal is not normally to be
used.
RS 485 interface, serial
68, 69
communication. Where the VLT
frequency converter is
connected to a bus, switches 2
and 3 (switches 1- 4 - see next
page) must be closed on the first
and the last VLT frequency
converter. On the remaining VLT
frequency converters, switches 2
and 3 must be open. The factory
setting is closed (position on).
MG.60.C4.02 – VLT is a registered Danfoss trademark
