Display mode
In normal operation, any 4 different operating
variables can be indicated continuously: 1.1
and 1.2 and 1.3 and 2. The present operating
status or alarms and warnings that have
arisen are shown in line 2 in the form of a
number. In the case of alarms, the alarm in
question will be shown in lines 3 and 4,
accompanied by an explanatory note.
Warnings will flash in line 2, with an
explanatory note in line 1. In addition, the
display shows the active Setup.
The arrow indicates the direction of rotation;
here the VLT frequency converter has an
active reversing signal. The arrow body
disappears if a stop command is given or if
the output frequency falls below 0.01 Hz.
The bottom line gives the status of the VLT
frequency converter.
The scroll list on the next page gives the
operating data that can be shown for variable
2 in display mode. Changes are made via the
[+/-] keys.
VAR 1.1 VAR 1.2
VAR
STATUS
MG.60.C4.02 – VLT is a registered Danfoss trademark
®
VLT 6000 HVAC
The table below gives the operating data options
for the first and second line of the display.
Scroll-list:
Resulting reference, %
Resulting reference, unit
Frequency
% of maximum output frequency
Motor current
Power
Power
Output energy
Hours run
Used-defined readout
Setpoint 1
Setpoint 2
Feedback 1
Feedback 2
Feedback
Motor voltage
DC-link voltage
Thermal load on motor
Thermal load on VLT
Input status, dig. input
Input status, analogue terminal 53
Input status, analogue terminal 54
Input status, analogue terminal 60
SETUP Pulse reference
1
External reference
Heat sink temperature
User-defined text
Three operating data values can be shown in the
first display line, while one operating variable can
be shown in the second display line. To be
programmed via parameters 007, 008, 009 and
010 Display readout.
Unit:
[%]
[unit]
[Hz]
[%]
[A]
[kW]
[HP]
[kWh]
[hours]
[unit]
[unit]
[unit]
[unit]
[unit]
[unit]
[V]
[V]
[%]
[%]
[binary code]
[V]
[V]
[mA]
[Hz]
[%]
[°C]
[-]
