Hoymiles DTU-G100 3rd Gen User Manual

Single-phase microinverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Open Energy for All
Single-phase Microinverter
USER MANUAL
DTU-G100 3rd Gen
Region: North America V202105
hoymiles.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTU-G100 3rd Gen and is the answer not in the manual?

Questions and answers

Related Manuals for Hoymiles DTU-G100 3rd Gen

Summary of Contents for Hoymiles DTU-G100 3rd Gen

  • Page 1 Open Energy for All Single-phase Microinverter USER MANUAL DTU-G100 3rd Gen Region: North America V202105 hoymiles.com...

  • Page 2: Table Of Contents

    3.4 Interface Layout 3.5 Local Installation Assistant 3.6 System Installation Sequence 3.7 DTU Installation Procedure 4. Site Creation on S-Miles Cloud (Hoymiles Monitoring Platform) 5. Customer Login 6. Complete Installation Map 7. Browse the Web-Based Plant 8. View Phone App 9.

  • Page 3: Important Safety Information

    • Note that only professionals may install or replace DTU. • Do not try to repair the DTU without approval from Hoymiles. If the DTU is damaged, send the DTU back to your installer for repairing/replacement. Disassembling the DTU without approval from Hoymiles will invalidate the remaining warranty period.

  • Page 4: About Hoymiles Microinverter System

    The DTU The DTU is a key component in the Hoymiles microinverter system. It works as the communication gateway between the Hoymiles microinverters and the S-Miles Cloud (Hoymiles Monitoring Platform). The DTU communicates wirelessly with the microinverters via 2.4 GHz Proprietary RF (Nordic), and collects the operation data of the system.

  • Page 5: Dtu Installation

    Reset Bottom SIM Card Slot Local Installation Assistant The Local Installation Assistant is a new function integrated with the DTU-G100 3rd Gen. Download the Installer App (for installer/distributor use only) before use. © 2021 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 6: System Installation Sequence

    Refer to the microinverter’s Manual or Quick Installation Guide for detailed installation steps. 2) Locate the DTU The maximum communication distance of Hoymiles DTU is 150 m in open space. The walls, roofs, or other obstacles in between will affect the signal and reduce the communication distance in actual installations.
  • Page 7 40 seconds to indicate the DTU self-check. After this, the green light will flash until networking is complete. Note: (1) Non-professionals must not modify other parameters. (2) The “Reset” button on the DTU shell is only for customers who use the enterprise Wi-Fi. © 2021 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 8: Site Creation On S-Miles Cloud (Hoymiles Monitoring Platform)

    4. Site Creation on S-Miles Cloud (Hoymiles Monitoring Platform) Install the Hoymiles Installer App by searching “Hoymiles” at App Store (iOS) or Google Play (Android). Open the app and log in with your installer account name and password. If you are a new installer with Hoymiles, apply for an installer account from your distributor in advance.

  • Page 9: Complete Installation Map

    Complete the system information of the installation map as shown below. To sheet _______ Panel Group: Customer Information: DTU Serial Number: NSEW Azimuth: (circle one) Tilt: Sheet _ of _ To sheet _______ © 2021 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 10: Browse The Web-Based Plant

    Single-phase Microinverter User Manual 7. Browse the Web-Based Plant Log in to your account and browse the web-based plant. © 2021 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 11: View Phone App

    8. View Phone App Download the mobile phone app by searching “Hoymiles” at App Store (iOS) or Google Play (Android) and log in with the customer/installer account name and password, after which you will be able to view the operating details of all installed microinverters there.

  • Page 12: Led Indicator Working Status Description

    5 V/2 A Power consumption 1.0 W (Typical), 5 W (Max) Mechanical Data Ambient temperature (°C) -20 to 55 Dimensions (W × H × D mm) 143 × 33 × 12.5 © 2021 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 13 Single-phase Microinverter User Manual Weight (kg) Mounting system Direct power supply Display LED indicator light Others EN 60950 EN 61000-3-2 EN 61000-3-3 Standard FCC Part 15B/15C © 2021 Hoymiles Power Electronics Inc. All rights reserved.
