12 | Smart Thermostat Product Manual
Manual Configuration of HVAC System
on Thermostat
The system type listed in the table below can be
physically set on the thermostat by doing
the following:
1. Put thermostat in OFF mode.
2. Press and hold the UP button for 5 seconds
until the display shows a version number.
3. Press and hold the UP button again for
5 seconds until the display shows your
HVAC setup.
4. Press the UP or DOWN buttons to
select the thermostat configuration from the
table below.
5. Press the MODE
button to confirm
your selection.

OPERATION

Display
1. Press any button to wake the thermostat up.
2. After waking, the display will show the current
mode and room temperature.
3. Press the UP or DOWN
button once
to display the current set point.
• The mode icon HEAT or COOL
will begin to pulse.
4. Press the UP or DOWN button again
to adjust to the desired set point.
Smart Thermostat Product Manual | 13
5. Press the MODE
button at any time to
change the mode.
• The modes are HEAT , COOL , AUTO,
EMER and OFF.
• EMER mode is available for Heat Pump
systems. Press and hold the mode button
while in Heat Mode to enter EMER.
• When in EMER mode, the display will read
EMER when the thermostat wakes up and the
HEAT icon will be displayed. Changing the
mode will leave EMER mode.
• In AUTO, the brighter icon will indicate which
set point is currently displayed and active
HEAT or COOL .
• After 5 seconds the display will return to the
current room temperature. The mode icon will
become solid to indicate this. If powered by the
"C" wire, the thermostat display will remain lit.
If the thermostat is running on battery power
only, the display will turn off after 5 seconds to
conserve energy. The thermostat will continue to
operate while the display is off.
