- Page 1 CK492300TX Devonshire Two-Tone Console Assembly Instructions For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 service@seidal.com www.seifurniturestore.com PO： Page | 1...
- Page 2 Devonshire Two-Tone Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Devonshire Two-Tone Console Assembly Instructions Attach Side Frame (B) to Bottom Shelf (C) using Bolt (2), Spring Washer (4) and Flat Washer (3). Tighten bolt with Allen Wrench (5) Figure 1 Attach the pre-assembled unit to the Top Panel (A), and then pull the drawer out of the Top Panel (A).
- Page 4 Secure the Side Frame (B) into Top Panel (A) using Bolt (1), Spring Washer (4) and Flat Washer (3). Tighten bolt with Allen Wrench (5) Figure 3 Turn the assembled console table over and it is ready to use. Figure 4 Page | 4...
- Page 5 For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
