- Page 1 CK499200TX PASCHALL END TABLE For assistance with assembly, contact. Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO:13876 Top supports up to Shelf supports up to...
- Page 2 CK499200TX PASCHALL END TABLE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. 2PCS 4PCS 4PCS Frames Supports Legs 4PCS...
- Page 3 CK499200TX PASCHALL END TABLE Assembly Instructions Step 1 Unit assembly should begin with parts turned upside down for Step Attach Metal Caps (4), Metal Washers (5) and Supports (2) to Top Frame (1) connecting with Screws (A) as shown. Please make sure the labels reading BOTTOM under Frames (1) are facing upwards.
- Page 4 Step 3 Attach Metal Washers (5) to Screws (A), and then attach Legs (3) to Metal Washers (5). Clockwise to tighten the parts. Screw Levelers (C) to Legs (3). Figure 3 Step 4 Attach Glass Pads (B) to the brackets on Frames (1). Place Glass Top (6) to Top Frame (1) and insert Mirror Shelf (7) to Shelf Frame (1) as shown.
- Page 5 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
