Modulation Analysis (Demod Mode)
One-View Display
VIEW: SELECT key
The selected view is surrounded by a white box.
Figure 3- 33: One-view display
3- 36
Three views are displayed on screen by default. To display one view, perform the
following steps:
1. Press the VIEW: DEFINE key on the front panel.
2. Select a view to make the single display by pressing the SELECT key in the
VIEW area. The selected view is surrounded by a white box.
3. Press the Show Views side key to select Single.
Figure 3- -33 shows the one view display.
Single
VIEW: DEFINE key
One-view display
