VIVOTEK
Configuration Area
Client Settings: Click this button to access the client setting page. For more information, please refer to
Client Settings on page 31.
Configuration: Click this button to access the configuration page of the Network Camera. It is suggested
that a password be applied to the Network Camera so that only the administrator can configure the
Network Camera. For more information, please refer to Configuration on page 36.
Language: Click this button to choose a language for the user interface. Language options are available
in: English, Deutsch, Español, Français, Italiano, 日本語 , Português, 簡体中文 , and 繁體中文 . Please
note that you can also change a language on the Configuration page; please refer to page 36.
Hide Button
You can click the hide button to hide or display the control panel.
Resize Buttons
:
Click the Auto button, the video cell will resize automatically to fit the monitor.
Click 100% is to display the original homepage size.
Click 50% is to resize the homepage to 50% of its original size.
Click 25% is to resize the homepage to 25% of its original size.
Live Video Window
■ The following window is displayed when the video mode is set to H.264 or H.265:
H.264/265 Protocol and Media Options
Video Title Time
2017/03/25 17:08:56
Video (TPC-AV)
Title and Time
Video 17:08:56 2017/03/25
Zoom Indicator
x4.0
Video Control Buttons
Video Title: The video title can be configured. For more information, please refer to Video Settings on
page 48.
H.264 or H.265 Protocol and Media Options: The transmission protocol and media options for H.264 or
H.265 video streaming. For further configuration, please refer to Client Settings on page 31.
Time: Display the current time. For further configuration, please refer to Media > Image > Genral settings
on page 48.
Title and Time: The video title and time can be stamped on the streaming video. For further configuration,
please refer to Media > Image > General settings on page 53.
User's Manual - 27
