IP9165-LPC
License Plate Capturing Solution
Highway & Street
Installation Guide
Rev. 1.0
Document part no.: 625046000G
Ordering part no.:
IP9165-LPC (Highway):
199004200G
IP9165-LPC (Street):
199004100G
IP Sur veillance

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP9165-LPC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivotek IP9165-LPC

Summary of Contents for Vivotek IP9165-LPC

  • Page 1 IP9165-LPC License Plate Capturing Solution Highway & Street Installation Guide Rev. 1.0 Document part no.: 625046000G Ordering part no.: IP9165-LPC (Highway): 199004200G IP9165-LPC (Street): 199004100G IP Sur veillance...

  • Page 2: Specifications

    CAUTION: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. UNPACKING: Unpack carefully. Electronic components can be damaged if improperly handled or dropped. If an item appears damaged in shipment, place it properly in its carton and notify the shipper.
  • Page 3 Please note the following for different applications: If you use IP9165-LPC for parking area or highway, you must select the LPR scene mode. Depending on the car speed at your surveillance scene, please select an appropriate scene mode: Maximum car speed...

  • Page 4: Mounting Configuration & Dimensions

    Mounting Configuration & Dimensions Swivel Positions and Directions 170 mm 502.8 mm 400 mm 255 mm 105 mm USABLE USABLE AREA AREA 502.8...

  • Page 5: Component Description

    Component Description Window frame heater Ventilation fan coil Camera Mounting Platform Power distribution M16 1/2" Waterproof cable gland board Installation Suggestions If you plan to install this camera enclosure into a tropical, sea coastal, or an environment where salt water or corrosive industrial waste water/moist are present, please seal each stainless steel screws and fittings with a silicon grease compounds.

  • Page 6: Installation

    Installation Install the wall-mount bracket to a preferred location at your installation site. Drill mounting holes and a cable routing hole (if preferred) on a wall. Install the bracket. Prepare and route the wiring, Ethernet and 24V power source. Install the IR illuminator to the bottom of the housing. Attach the included grip stricker to the U bracket.
  • Page 7 Secure the U bracket to the IR illuminator using the included wrench and hex screws. Flip the housing over and place it on a clean, stable surface. Secure the IR illuminator to the bottom of the housing using the included wrench and a hex socket screw.
  • Page 8 You can turn the IR illuminator so that its flat side is parallel with the housing, and that you can turn the assembly over and work on the inside of the housing. Put a foam pad below before you work on the wiring to avoid scratching the surface. Prepare power wires, a ground wire, and a CAT5e Ethernet cable.
  • Page 9 Assemble the camera components, e.g., the CS ring and lens module. Secure the mounting plate to the bottom of the camera (the label side) using the included screw. There is a plastic mount pad in the package. You do not need the mounting pad using the VIVOTEK camera.
  • Page 10 Adjust the camera's position so that the lens module can flush align with the tempered glass. Secure the camera using the screws and washers to the bottom of the housing. Lens flush w/ edge of enclosure Connect 24V power source to the power input terminal. Connect power wires from the DC 12V output to the camera.
  • Page 11 IMPORTANT: You should prepare a power adaptor of the sufficient capacity for supplying 24V input. Below are the requirements: Total consumption Power adaptor LPC Highway LPC Street Connect the Ethernet cable to the camera's RJ45 socket. Also pass the combo cable of the IR illuminator through a waterproof connector. Connect the day/night signal lines from the IR unit to the DI/DO connectors on the camera's terminal block.
  • Page 12 A sample connection diagram consisting of CaMate's IR illuminators and the camera is shown below. Please refer to your camera's documentation if your camera comes with different pinouts. Camera terminal block AWG26 DI+: Green DI-: Yellow DO+: Purple DO-: Blue RS485+: Orange RS485-:...
  • Page 13 Secure the intersection bracket to the bottom of the housing by driving two screws. Install the housing to the wall-mount bracket by aiming and pressing the spring mortise, and hook the bracket onto the groove in the spring mortise.
  • Page 14 When mounting the housing, please carefully place the cable within the cutout on the bracket. There is a cutout for routing the cable. Secure the housing to the bracket by fasteninng 4 T30 screws. T30 x 4...
  • Page 15 Adjust zoom and focus and open a web console with the camera to tune for the best image. When zoom and focus is done, Close the top cover and fasten the hex screws from below. Firmware configurable options: Make sure that the external IR is turned on in the night mode, and that the IR cut filter option is synchronized with the digital input you connected (default is DI1).
  • Page 16 If using an iCS lens model, use the auto focus function for an optimal image. The configuration page automaticallly displays different options according to the lens you installed. iCS lens...
  • Page 17 In the Configuration > Media > Image settings page, select an application scenario, LPC Highway, street, or parking lot mode. The related parameters, such as shutter time, will be automatically changed for the scenario. LPC-highway LPC-street LPC-parking lot If preferred, e.g., shooting fast moving vehicles, select the 60fps frame rate.
  • Page 18 In the night mode, check if the input signals are correctly detected. You may simulate the night mode by blocking the IR unit's light sensor. Change the triggering parameters if necessary. Note that the IR unit does not immediately turns on or off. There is a 30-second buffer time.
  • Page 19 The parameters of IR illuminator can be controlled via the RS485 connection. You can enable the connection in the Configuration > PTZ > Mechanical window. Select the defaults for the IR illuminator: Pelco D, baud rate - 38400, Data bits - 8, Stop bit - 1, Parity - none.
  • Page 20 If you need to cascade multiple IR units via the RS485 bus, please contact CaMate (http:// www.lidlight.com/) for a mobile app through which you can change device ID, baud rate, and so on. With a motorized IR unit, the IR light zoom control buttons will be available on the home page of the camera web console.
  • Page 21 Below is the table of configurable data bit (Data1 ~ Data4) values: bit 31 ~ 24 Device ID: 01 (default) ~ 127 bit 23 ~ 21 Baud rate (0)1200, (1)2400, (2)4800, (3)9600, (4)19200, (5)38400 (default), (6)57600, (7)115200 bps bit 20 ~ 16 Brightness: (0) ~ (31), brightness from 0 ~ 100% (default), increment unit is 2.5% bit 15 ~ 13 LED control mode: (0) DI, (1) Direct, (2) Timer, (3) Light sensor, (4) DI pulse, (5) LPR, (6)
  • Page 22 Brightness 70% FF012101b40009E0 Brightness 60% FF012101b00009DC The customized buttons will appear on the main page for easy access to IR control.
