- Page 1 For use with models: BP2400-24, BP2400-110-220, EPA Establishment number: 92866-TX-1 For safety and to ensure proper use carefully read the contents of this manual before operating or installing the unit. R2020.06.05...
- Page 2 2400 please read this manual in its entirety. Doing so will give you important information to keep you safe from harm and ensure you get the most benefits from your air purifier. For additional information please contact us: Mail: Air Oasis, LLC web: www.airoasis.com Attn: Customer Service e-mail: feedback@airoasis.com 3401 Airway Blvd.
- Page 3 Important Safety Instructions When operating any electrical appliance, basic precautions should always be fol- lowed for safety. RISK OF FIRE, ELECTRIC SHOCK, OR INJURY • Carefully read the entire contents of this manual. • Do not use outdoors. • Do not use the unit in areas of extreme heat or in the presence of flammable gas.
- Page 4 Maintenance & Installation The Bi-Polar 2400 was engineered to have low maintenance. The brush heads on ® your unit should be cleaned periodically for optimal effectiveness. The Bi-Polar 2400 can be installed using included screws, zip ties, or neodymium ® Magnets as shown below.
- Page 5 Optimal Mounting Locations Ptac Installation Ceiling Mount Installation Furnace Installation 2400...
- Page 6 Only trained and quali- fied service personnel should install, repair, or service air-conditioning equipment. Air Oasis and its affiliates are not responsible for any damage to the Bi-Polar ® unit, or injury to yourself or others, if you elect to install the device without utilizing qualified technicians.
- Page 7 Check with your local electric codes and follow all guidelines. 2. Review the model number found on the Bi-Polar 2400 product and wire it only to the voltage range shown below. Disconnect power to the air handler the Bi-Polar 2400 will be mounted to during installation.
- Page 8 Step 3 - Using the included self-tapping screws, attach the Bi-Polar 2400 as shown in the illustration below. Step 4 - Wire the Bi-Polar 2400 to the power distribution block. The wires are not polarity sensitive and may be shortened as required. Make sure to use the proper Bi-Polar model based on the primary voltage.
- Page 9 Step 1 - Disconnect power to air conditioner, remove service access panels and locate fan compartment. Using either the included self-tapping screws, zip ties, or clear adhesive strips, mount the Bi-Polar 2400 within the airstream as illustrated below. Step 2 - Wire the Bi-Polar’s black and red wires to the proper voltage terminals on the power distribution block as illustrated on page 3.
- Page 10 Step 4 - Wire Bi-Polar to the power distribution block as illustrated on page 3. The wires are not polarity sensitive and may be shortened as required. Make sure to use the proper Bi-Polar model based on the primary voltage. Step 5 - Enjoy the many benefits of the Bi-Polar 2400!
- Page 11 God, the use of voltages other than indicated on the label displayed on this product or service of this product by anyone other than Air Oasis or an Air Oasis authorized dealer. ®...
- Page 12 How do I clean debris off the Using any non abrasive object, lightly brush the heads brush heads? to remove debris. If the above does not repair the symptom please contact an Air Oasis Customer Service Representative: Phone: 1-800-936-1764 E-mail: feedback@airoasis.com Web: www.airoasis.com...
