Troubleshooting Guide
Problem/Question
Solution/Answer
What if my Bi-Polar won't
Check to make sure the Bi-Polar is properly installed with
turn on? The indicator light
the black and red wires securely connected to the power
is not illuminated.
source.
How do I know my Bi-Polar
First check to see that the green indicator light is illuminat-
2400 is working?
ed. A voltage detector can be placed between the brushes.
If a voltage is detected then the unit is working properly.
How do I clean debris off the
Using any non abrasive object, lightly brush the heads
brush heads?
to remove debris.
If the above does not repair the symptom please contact an Air Oasis Customer Service
Representative:
Phone: 1-800-936-1764
E-mail: feedback@airoasis.com Web: www.airoasis.com
Mail: Air Oasis
Customer Service
3401 Airway Blvd.
Amarillo, TX 79118
Bi-Polar 2400 Specifications
Operational
BP2400-24 Coverage
BP2400-110 Coverage
BP2400-220 Coverage
Ozone
Warranty
Replacements
The Bi-Polar 2400 requires
Electrical
BP2400-24 Usage
BP2400-110 Usage
BP2400-220 Usage
Mechanical
BP2400-24 Dimensions
Weight of Unit
Shipping Weight
BP2400-110 Dimensions
Weight of Unit
Shipping Weight
BP2400-220 Dimensions
Weight of Unit
Shipping Weight
Copyright© 2014 Air Oasis LLP
Up to 2400 CFM
Up to 2400 CFM
Up to 2400 CFM
0 ppm
One year limited warranty
no replacement parts.
24 VAC / 400mA
110-120 VAC / 80mA
208-277 VAC / 40mA
4" W x 2" H x 1.3" D
0.25 lbs
2 lbs
4" W x 2" H x 1.3" D
0.25 lbs
2 lbs
4" W x 2" H x 1.3" D
0.25 lbs
2 lbs
For use with models: BP2400-24, BP2400-110, BP2400-220
For safety and to ensure proper use carefully read the
contents of this manual before operating or installing the unit.
Advertisement
Table of Contents
Related Manuals for Air Oasis Bi-Polar 2400-24
Summary of Contents for Air Oasis Bi-Polar 2400-24
-
Page 1: Troubleshooting Guide
How do I clean debris off the Using any non abrasive object, lightly brush the heads brush heads? to remove debris. If the above does not repair the symptom please contact an Air Oasis Customer Service Representative: Phone: 1-800-936-1764 E-mail: feedback@airoasis.com Web: www.airoasis.com... - Page 2 ® ® Congratulations, you own the MOST Versatile HVAC Air Purifier available! Before Air Oasis gives you the following limited warranty for this product only if it was origi- operating the Bi-Polar ® please read this manual in its entirety. Doing so will give nally purchased directly from Air Oasis or an Air Oasis authorized dealer.
-
Page 3: Installation Instructions
Installation Instructions Important Safety Instructions When operating any electrical appliance, basic precautions should always be fol- Ceiling Mount lowed for safety. Step 1 - Confirm power is disconnected from the air conditioner and remove face RISK OF FIRE, ELECTRIC SHOCK, OR INJURY panel, exposing fan compartment. - Page 4 Maintenance & Installation Installation Instructions The Bi-Polar 2400 was engineered to have low maintenance. The brush heads on ® Mini Split Installation & Ptac Installation your unit should be cleaned periodically for optimal effectiveness. Step 1 - Disconnect power to air conditioner, remove service access panels and locate fan compartment.
-
Page 5: Ceiling Mount Installation
Installation Instructions Optimal Mounting Locations Furnace Installation Step 1 - Confirm power is disconnected from AHU and remove face panel, expos- Mini Split ing fan compartment. Installation Step 2 - Locate power distribution block where main power is or will be connected to unit. - Page 6 5. Green light will illuminate when powered and operating correctly. system pressure and electrical components. Only trained and qualified service personnel should install, repair, or service air-conditioning equipment. Air Oasis Black wire: Neutral or Ground and its affiliates are not responsible for any damage to the Bi-Polar unit, or injury ®...
