CAUTION: At least two installers are
required due to the weight and size of the
hood.
ELECTRONICS
MOUNTING
BRACKET
FIG. F
9. Install electrical and duct work. Seal duct work with aluminum duct tape.
10. Power up hood, verify all functions and check for leaks around duct tape.
1
2
11
1
FIG. H
