Summary of Contents for Greenlee GATOR CUAP32GL
- Page 1 INSTRUCTION MANUAL CUAP32GL Pressing Tool 120 Volt and 230 Volt 999 4508.8 GATOR Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. © 2002 Greenlee Textron ® IM 1517 8/02...
-
Page 2: Table Of Contents
Replacement manuals are available upon request at no charge. All specifications are nominal and may change as design improve- ments occur. Greenlee Textron shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Greenlee Textron. -
Page 3: Important Safety Information
Failure to observe this warning will result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. Electric shock hazard: This tool is not insulated. When using this unit on or near energized electrical lines, use proper personal protective equipment. - Page 4 Failure to observe this warning can result in severe injury or death. Inspect tool and dies before use. Replace any worn or damaged parts with Greenlee replacement parts. A damaged or improperly assembled tool can break and strike nearby personnel.
-
Page 5: Identification
CUAP32GL22 ... 230 VAC, 50 Hz, 1.1 A Hydraulic Oil ... 50 ml (0.1 pint) of Shell Tellus Maximum Pressing Force ... 32 kN (3.6 tons) Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070 ®... -
Page 6: Operation
Failure to observe this warning can result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. • Do not operate the tool without dies. Damage to the ram or tool head can result. -
Page 7: Maintenance
2. Check the oil level. Annually or Every 10,000 Pressing Cycles 1. Replace the hydraulic oil. 2. Send the tool to an authorized Greenlee service center for inspection. Checking the Oil Level 1. Remove the two screws that retain the tank housing cover. -
Page 8: Troubleshooting
CUAP32GL Pressing Tool Troubleshooting Problem Tool is inoperative. Dies stop during operation. Tool loses oil. Greenlee Textron / Subsidiary of Textron Inc. Probable Cause Dirt, contaminants, etc., in ram area of tool. Tool components worn or damaged. Oil level is low. -
Page 9: Disassembly
(107). 13. Remove screws (108) and separate the gear housing/motor subassembly from the pump housing. Greenlee Textron / Subsidiary of Textron Inc. Pump 1. Use a hooked tool to remove the reservoir O-ring (80). Gently tug it over the reservoir. -
Page 10: Assembly
Using a hooked tool, carefully slip the O-ring over the lip of the pump housing. 7. Insert the plug (76) into the reservoir. Greenlee Textron / Subsidiary of Textron Inc. Main Components 1. Remove the protective plastic bag from the electronics subassembly. -
Page 11: Illustrations
CUAP32GL Pressing Tool Illustration Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070... - Page 12 CUAP32GL Pressing Tool Illustration Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070...
- Page 13 CUAP32GL Pressing Tool Illustration Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070...
-
Page 14: Parts List
500 7337.0 500 1563.0 500 1564.8 500 4207.6 500 1565.6 500 1567.2 Greenlee Textron / Subsidiary of Textron Inc. Description Decal, identification ... 1 Decal, safety, 120 volt ... 1 Decal, safety, 230 volt ... 1 Decal, pinch hazard ... 2 Plate with microswitch, 120 volt ... - Page 15 500 8403.8 500 8402.2 500 1573.7 500 1574.5 500 1580.0 Greenlee Textron / Subsidiary of Textron Inc. Description Compression spring ... 1 Film insulation (not shown) ... 1 Plug (not shown) ... 1 Pump housing, reservoir assembly (includes items 72–83) Threaded bushing ...
- Page 16 501 0367.9 501 0368.7 500 1411.0 500 1623.7 Greenlee Textron / Subsidiary of Textron Inc. Customer Service (International): 815/397-7070 • Fax: 815/397-9247 Customer Service (North America): 800/435-0786 • USA Fax: 800/451-2632, 815/397-1865 Greenlee Textron / Subsidiary of Textron Inc. Description Relief valve assembly (includes items 120–130)
