Tektronix Keithley DMM7510-FUSE-3A Quick Start Manual

3.5 a fuse kit

Keithley Instruments

28775 Aurora Road

Cleveland, Ohio 44139

1-888-KEITHLEY

http://www.keithley.com

Description

The Model DMM7510-3A is a 3.5 A, 1000 VAC/VDC fast blow fuse.

Make sure the instrument is disconnected from the power line and other equipment before

checking or replacing a current-input fuse. Failure to disconnect all power may expose you to

hazardous voltages, that, if contacted, could cause personal injury or death. Use appropriate

Safety Precautions when working with hazardous voltages.

For continued protection against fire or instrument damage, only replace fuse with the type and

rating listed. If the instrument repeatedly blows fuses, locate and correct the cause of the problem

before replacing the fuse.

Manufacturer and part number

DMM7510-FUSE-3A

Refer to the Maintenance section of the documentation for your instrument for fuse replacement instructions.

If the fuse continues to blow, a circuit malfunction exists and must be corrected. Return the

instrument to Keithley Instruments for repair.

077108800 / December 2014

Figure 1: Model DMM7510-FUSE-3A Fuse Kit

Rating

3.5 A, 1000 VAC/VDC fast blow

*P077108800*

Model DMM7510-FUSE-3A

Length

10 mm x 38 mm (0.394" x 1.5")

3.5 A Fuse Kit
