- Page 1 Owner’s Manual 185DC REVISED 6/22/05...
- Page 2 Dear EdgeWater 185CC Owner: Congratulations on purchasing one of the finest small boats ever built. It has been constructed with care from the finest available materials. At EdgeWater we take great pride in the quality and craftsmanship that goes into each boat, large or small. We believe you’ll have many years of enjoyment from your new EdgeWater and thank you for entrusting your leisure time to one of our fine products.
- Page 3 Service Information Please fill out the information below completely. It will help us in assisting you in the event your EdgeWater needs service. Customer Name ______________________________________________________________________ Address _____________________________________________________________________________ City __________________________________________ State Phone _________________________Cell _____________________Business _____________________ E-mail Address _______________________________________________________________________ Dealer Name _________________________________________________________________________ Address _____________________________________________________________________________ City ___________________________________________ State ______ Zip ______________ Phone _________________________________________ Fax __________________________________...
-
Page 4: Table Of Contents
Table of Contents Chapter 1 General Information ..............6 1.1 General ..........................6 1.2 Owner / Operator Responsibilities ..................6 Chapter 2 Helm Control Systems..............7 2.1 General ..........................7 2.2 Steering System........................7 2.3 Engine Throttle and Shift Controls ..................7 Chapter 3 Propulsion System..............8 3.1 General .......................... - Page 5 7.5 Locker Drains ........................17 Chapter 8 Safety Equipment..............17 8.1 Required Safety Equipment ....................17 8.2 Suggested Safety Equipment - Inshore ................18 8.3 Suggested Safety Equipment – Offshore................19 Chapter 9 Safe Operation.................19 9.1 Pre-Cruise Check List ......................19 9.2 Basic Rules of the Road ....................20 9.3 Safe Operation........................
-
Page 6: Chapter 1 General Information
1/General Information 1.1 General The EdgeWater 185DC is a semi-custom fishing vessel designed to be powered by a single outboard engine. 1.2 Owner / Operator Responsibilities Registration Registering your boat is important to you. Federal Law requires that all powered, undocumented vessels be registered in their state of principal use. -
Page 7: Chapter 2 Helm Control Systems
2/Helm Control Systems 2.1 General The helm station is the control center for the boat. The main control systems are the engine throttle and shift controls, the steering system, and the trim tab controls. These provide the operator the ability to control speed, direction, boat trim, and attitude. Each manufacturer provides manuals on the operation and use of their systems. -
Page 8: Chapter 3 Propulsion System
3/Propulsion System 3.1 General Your new EdgeWater 185DC is designed to be powered by a single outboard motor. Most 2- cycle outboards currently use an automatic system to mix the oil with the gasoline before the engine uses it. If equipped with a 2-cycle engine, there will be an oil tank in the aft port locker. -
Page 9: Engine Cooling System
Do not paint your outboard’s lower unit with paints designed for boat hulls. Some can cause severe damage to your engine. Check with your engine manufacturer to get their recommendation. Do not attempt control adjustments unless you are very familiar with their function, operation and adjustment. -
Page 10: Engine Power Tilt And Trim
The power tilt and trim system on your outboard provides the ability to optimize the running angle of your EdgeWater 185DC to allow for load and sea conditions. Moving the outboard lower unit toward the transom is generally referred to as trimming “in”, while moving the outboard lower unit away from the transom is referred to trimming “out”. - Page 11 Temperature Gauge This is designed to monitor the operating temperature of your engine’s cooling system. A sudden rise from the normal should be investigated to determine if there is an obstruction in the cooling system. Water Pressure Gauge This gauge measures pressure in the engine cooling system. If the pressure changes from the norm it could indicate a complete or partial blockage in the system or a water pump problem.
-
Page 12: Chapter 4 Fuel System
Make sure this vent is kept free from debris. 4.4 Fueling Your EdgeWater 185DC is equipped with a built-in 54 gallon fuel tank. Before fueling, you should follow these procedures. Make sure the boat is securely moored. -
Page 13: Fuel System Maintenance
4.6 Fuel Filters A fuel filter is installed in the transom area of your EdgeWater 185DC. This is a fuel/water separator type of filter and is designed to prevent water from entering your engine. The fuel filter element is a spin-off type element. At a minimum, this element should be replaced at the beginning of every boating season. -
Page 14: Electrical System Maintenance
When equipped with dual batteries the boat will have a battery selector switch which provides isolation for each battery and also provides the ability to have a back-up in case of a dead or weak battery. When in port and running accessories such as entertainment equipment or pumps, the selector switch should be set on “1”... -
Page 15: High Pressure Washdown
6.3 High Pressure Washdown The washdown system is comprised of a diaphragm pump mounted on the hull inside the port side transom seat and a washdown fitting to attach a hose. The pump is controlled by the washdown switch on the control panel. The diaphragm pump is fed through the same thru hull and high speed pickup as the livewell pump. -
Page 16: Chapter 7 Drainage System
7/Drainage System 7.1 General All water drains from your EdgeWater 185DC by gravity. Your boat is self-bailing at rest. It is important to check drains frequently to make sure they are clear and free flowing. Review the schematic in the Appendix and become familiar with the location of each thru-hull drain. -
Page 17: Locker Drains
7.5 Locker Drains On the 185DC, the port forward locker drains to the deck at the rear of the passengers console and the starboard locker has an overboard drain. The 185DC does not have a true anchor locker, it is suggested that the starboard locker be used as such, as it drains overboard. -
Page 18: Suggested Safety Equipment - Inshore
• Pyrotechnic Visual Distress Signals These must be U.S. Coast Guard approved, be in a serviceable condition, and be readily accessible. They each have a service life date and are not counted beyond this date. These types include both hand held flares and aerial flares. •... -
Page 19: Suggested Safety Equipment - Offshore
• It is advisable to carry jackets or foul weather gear in the event of adverse weather conditions. Your EdgeWater 185DC is equipped with a maximum capacity rating plate permanently affixed to the helm area of your boat. It will provide information regarding the maximum number of people you can safely have aboard, the maximum amount of weight the boat can safely carry, and the maximum horsepower your boat was designed to handle. -
Page 20: Basic Rules Of The Road
• Check the emergency stop lanyard to see if it is properly attached, and that the shift lever is in the neutral position. • Check fuel and oil to make sure you have more than enough for the planned trip. Remember the rule of thirds: 1/3 out, 1/3 back, and 1/3 in reserve. -
Page 21: Safe Operation
Aids to Navigation Along the coast lines and in navigable inland waters, aids to navigation have been placed by the U.S. Coast Guard. These have been placed for the boating public’s safety. Please become familiar with them and learn to use them to make your boating safer and more fun. Federal Waterways Marking System Aids Lateral Aids as seen from Seaward (portside green) -
Page 22: Towing Or Being Towed
• After coming on plane, raise the trim to a point where the engine is level with or slightly above the plane of the water. This is usually with the bow at about 3 to 5 above level. This will provide the smoothest, most economical operation. -
Page 23: Docking
down. After docking and securing the boat, raise the trim tabs to the fully upright position and turn off the ignition. 9.6 Docking Safe docking keeps your boat from being damaged and is an indicator of a capable and knowledgeable captain. There are many docking maneuvers, which will be done while boating; only the basics will be discussed here. -
Page 24: Launching Your Boat
Make sure your vehicle is properly equipped to handle the load. This includes engine, hitch, frame, brakes, transmission cooler, and vehicle capacity. Securely attached the boat trailer to the vehicle hitch, hook the safety chains and cross them under the hitch and check the lights to ensure they are hooked up and vehicle working. -
Page 25: Chapter 10 Routine Maintenance
• Back the trailer into the water until the bunks are completely submerged, or until the middle roller is just touching the water. (This depth should provide enough to float the boat until the last minute and yet provide enough resistance from the trailer to stop the boat short of the winch stand.) •... -
Page 26: Engine
Anodized Aluminum The aluminum can be maintained with a regular washing with soap and water. Otherwise it can develop a surface corrosion, which can penetrate the anodizing and attack the aluminum underneath. If badly scratched, it can be repaired with an aluminum or silver paint. Chrome Hardware Use a good metal polish and protect with wax. -
Page 27: Chapter 11 Exterior Equipment
11.1 Swim Platform (optional) If your EdgeWater 185DC is equipped with the optional swim platform, there are several important things to remember for safe use and operation of this useful option. • Always shut down the engine if persons will be using the platform. Do not just settle for the engine being in neutral. -
Page 28: Storage
12.3 Storage • It is best to store the boat inside, however if inside storage is not available, use the following guidelines in order of preference • Under awning with no boat cover • Outside under a boat cover. (Boat cover should allow ample ventilation and be removed periodically to allow moisture to disapate avoiding mildew growth and staining. -
Page 29: Appendix
Appendix 185DC... - Page 31 Hydraulic Steering System...
