Reversing The Door Swing - EdgeStar BWC121SSLT Owner's Manual

Reversing the Door Swing

Warning: Before you begin, unplug the Refrigerator.
!
To Remove the Door:
1. Using a flathead screw driver carefully pry the top hinge cover off.
2. Using a Philips screwdriver, remove the screws and take off the top hinge. Keep the
parts together and set them aside.
3. Lift the door off the bottom hinge and set the door aside.
4. Remove the bottom hinge by removing the screws with a Philipa head screwdriver
To Install the Door:
1. Using a flathead screwdriver, remove the decorative plugs or cover from the opposite
cabinet top corner and from the door. Set the plugs or cover aside.
2. Install the bottom hinge at the opposite side corner and fasten the screws.
3. Position the door on the bottom hinge.
4. Align the door on the bottom hinge and install the top hinge.
5. Push the decorative plugs or cover into the corresponding holes.
10
