- Page 1 Built-in Wine Refrigerator BWR460BL Owner’s Manual For more information on other great EdgeStar products on the web, go to http://www.edgestar.com...
-
Page 2: Important Safety Information
Important Safety Information Improper handling can cause serious damage to the EdgeStar wine refrigerator and/or injury to the user. This wine refrigerator is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. -
Page 3: Table Of Contents
SPECIFICATIONS ....................12 EDGESTAR LIMITED WARRANTY ..ERROR! BOOKMARK NOT DEFINED. First Time Operating Instructions Before use, make sure all packaging labels and materials are all removed from the unit. Be sure to keep track of all included parts and pieces before discarding packaging materials. -
Page 4: Introduction
Introduction Thank you for purchasing this Koldfront wine refrigerator by EdgeStar. We are glad you chose us. We believe that your purchase of this product opens a relationship between you and EdgeStar. We will provide the customer support needed to nurture that relationship. -
Page 5: Parts Identification
Parts Identification Top Right Hinge Front View Control Panel Shelf Black trim Door Small Shelf Front vent Leveling foot Back View Product Label Tip: Gather the model and serial number from the product label and write them down before installing the wine refrigerator. -
Page 6: Installing The Wine Refrigerator
Installing the Wine refrigerator The wine refrigerator should be installed in accordance with local electrical code requirements. The wine refrigerator should also be placed in a location that is strong enough to support its total weight, keeping in mind that it will weigh substantially more when fully loaded than when empty. -
Page 7: Installation Clearance Requirements
Installation Clearance Requirements When installing the wine refrigerator under a counter, follow the recommended spacing dimensions shown. • To ensure proper service access and ventilation, allow at least 2/5” clearance at the back, 1/5” at top and 1/5” at sides. The installation should allow the unit to be pulled forward for servicing, if necessary. -
Page 8: Electrical Requirements
Electrical Requirements Plug into a grounded 3-prong outlet. Never remove the grounding prong from the plug. Never use an adapter to bypass the grounding prong. DO NOT use an extension cord. Failure to follow these instructions can result in fire, electrical shock, or death. -
Page 9: Installing And Removing The Shelves
Installing and Removing the Shelves To prevent damaging the door gasket, make sure to open the door all the way before pulling the shelves out of their track. To install the shelves: 1. Open the door completely. 2. Slide the shelf on the shelf track and slowly push back until it stops. 3. -
Page 10: Reversing The Door Swing
Reversing the Door Swing Follow the instructions below to reverse the door swing. IMPORTANT: Before you begin, unplug the refrigerator. To reverse the door from right swing to left swing: 1. Open the door and using a Phillips screwdriver, remove the bottom screws from the lower hinge. -
Page 11: Operation
OPERATION Using the Temperature Control Panel Temp. Buttons Light Button Power Button Run Light Celsius and Fahrenheit Lights Upper Zone Display Lower Zone Display Use the up button to adjust the upper zone’s temperature, and use the down button to adjust the lower zone’s temperature. The temperature displayed can be in Fahrenheit or Celsius. -
Page 12: Normal Sounds
Normal Sounds Your new wine refrigerator may make sounds that are not familiar to you. Most of the new sounds are normal. Hard surfaces like the floor, walls can make the sounds seem louder than they actually are. The following describes the kinds of sounds that might be new to you and what may be making them. -
Page 13: Cleaning And Maintenance
CLEANING AND MAINTENANCE Periodic cleaning and proper maintenance will ensure efficiency, top performance, and long life. Exterior Cleaning The door and cabinet may be cleaned with a mild detergent and lukewarm water solution such as 2 tablespoons of baking soda to 1 quart of water. -
Page 14: Troubleshooting Continued
Troubleshooting continued Issue Possible cause Solution Ensure the cooler is plugged in and the power outlet has There is a power failure. power. Plug the unit in to a power outlet that has sufficient The cooler is not plugged in. The wine cooler does not amperage. -
Page 15: Specifications
Specifications Description of product Built-in Wine refrigerator Model BWR460BL Voltage/Frequency AC 115V~60Hz Amperage 1.8A Input Power 130W Color Black Cabinet; Black trim Door Storage Capacity 46 Bottles* Refrigerant R134a, 1.84 oz. Temperature Range 40 - 65ºF Dimensions 33 1/2” x 23 1/2” x 22 1/2” (Height x Width x Depth ) Weight 100 pounds... - Page 16 Once an EdgeStar authorized representative has confirmed that your product is defective and eligible for warranty service, the product must be returned to an EdgeStar authorized repair facility. EdgeStar is not responsible for damage resulting from shipper mishandling or improper packaging. Do not return a defective product to the place of purchase.
- Page 17 Register your product, download owner’s manuals, access additional troubleshooting resources, and obtain more information on other great EdgeStar products on the web at: http://www.edgestar.com Product contents and specifications may change without notice. Copyright © 2011 Living Direct, Inc. All rights reserved.
