Description
Meter Description
1. NCV sensor
2. Current clamp
3. Non-contact AC voltage indicator light
4. Clamp trigger
5. Data Hold/ Back Light button
6. LCD display
7. MODE select button
8. COM input jack
9. Rotary Function switch
10. Relative button
11. Range button
12. Hz% Hold button
13. V Ω CAP TEMP Hz jack
14. Battery Cover (rear)
Display icons Description
HOLD
AUTO
DC
AC
REL
V

A
F
Hz
%
o o
F and C
n, m, , M, k
)
 )
)
nd Quality Products Online at:
Data Hold
Autoranging
Direct Current
Alternating Current
Low battery
Relative
Volts (Voltage)
Ohms (Resistance)
Amperes (Current)
Farad (Capacitance)
Hertz (Frequency)
Duty Ratio
Fahrenheit and Celsius units (Temperature)
Unit of measure prefixes: nano, milli, micro, mega, and kilo
Continuity test
Diode test
