Decor Star PL-008-SS
Features
- Stunning stylish European inspired design
- Elegant silver stainless steel & Aluminum Two Tone Finish
- Durable stainless steel frame construction
- Horizontal massage jets with 50 nozzles
- 8" chrome square ABS rainfall shower head with 100 Nozzles
- 3 stage shower functions (Rainfall, Massage Spray, Hand Shower)
- Single function control. One water feature at a time.
Decor Star
1
PL-008-SS Rev. A3 122015
Advertisement
Related Manuals for Decor Star PL-008-SS
Summary of Contents for Decor Star PL-008-SS
- Page 1 - Horizontal massage jets with 50 nozzles - 8” chrome square ABS rainfall shower head with 100 Nozzles - 3 stage shower functions (Rainfall, Massage Spray, Hand Shower) - Single function control. One water feature at a time. Decor Star PL-008-SS Rev. A3 122015...
- Page 2 Thank you for purchasing Decor Star products. Please read the information below and keep this installation guide for future reference. If you require assistance, please contact our customer service department at 1-800-879-1197, Monday - Friday 10AM - 5PM Pacifi c Time. Or by email at support@decorstarusa.com.
- Page 3 • A laundry outlet box such as the Sioux Chief Ox Box can be used to speed up the installation process of the shut off valves. Decor Star PL-008-SS Rev. A3 122015...
- Page 4 NOTE: This distance vary by models, always take the actual measurement from the shower panel) (This is the distance from the oor to the bottom edge of the shower panel) Reference Model Height is 5’ 8” Decor Star PL-008-SS Rev. A3 122015...
- Page 5 Recommended Operating Pressure: 50 - 80 psi Approx. Flow Rate: 3.07 gpm at 80 psi 220mm 340mm 8.86” 13.39” 1250mm 49.21” 750mm 29.53” 535mm 21.06” 245mm 195mm 9.65” 7.68” 70mm *All Measurements are Approximate 2.76” Decor Star PL-008-SS Rev. A3 122015...
-
Page 6: Parts List
11. Rubber Washer 12. Elbow Connector 13. Locking Nut 14. Hand Shower Water Connector 15. Rubber Washer 16. Hand Shower Hose 17. Screws X 4 18. Mounting Brackets X 2 19. Wall Anchors X 4 Decor Star PL-008-SS Rev. A3 122015... -
Page 7: Installation
3. Mark the positions of the 2 brackets on the wall and set a side the panel. (NOTE: The distance between the two brackets should be 29.53” or 750mm) 750 mm 29.53” Decor Star PL-008-SS Rev. A3 122015... - Page 8 6. Apply thread sealant tape to the threading on the shut off valves before connect both hot and cold water supply hoses to the valves. Turn on the valves and check all connections for possible leaks. Decor Star PL-008-SS Rev. A3 122015...
- Page 9 8. Attache shower head. 9. Connect hand shower hose to the main panel body. Attach the hand shower to the hose. (NOTE: Install the rubber washer to prevent leak.) Decor Star PL-008-SS Rev. A3 122015...
-
Page 10: Operation
6. When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. 5. After cleaning, rinse thoroughly with clean water to remove any cleaner residue. Decor Star PL-008-SS Rev. A3 122015...
