PL-004-SS-TB
Features
- Stunning stylish European inspired design
- Elegant durable stainless steel frame construction
- 5 stage shower functions (Rainfall, Waterfall, Massage Spray, Hand Shower, Tub Spout)
- Independent valve control for each of the shower functions
- Simultaneous operation of all shower functions*
- Thermostatic valve control minimize the chance of scalding
- Contemporary brass hand shower
* Proper water pressure is required for simultaneous operations
Decor Star
1
PL-004-SS-TB Rev. C 022018
