Electrical Specifications - Extech Instruments PQ3470-2 User Manual

Datalogger
Data Output
Operating Temperature
Operating Relative Humidity
Power Supply
Power Consumption
Max. Conductor size
Weight
Dimensions
Accessories Included

2.2 Electrical Specifications

Function
AC Voltage
AC Voltage
(peak to peak)
AC Current (trms)
AC Current
(peak to peak)
Power Factor
Φ Phase Angle
Frequency
Power
Watt-Hour
*Meter accuracy only. For system accuracy add the accuracy of the clamp used.
800.561.8187
Real time data logger saves data to SD memory card for download to
PC (data files open directly to spreadsheet)
Sampling rate: From 2 seconds to 7200 seconds
Max. file capacity: 30,000 records
Serial or USB connection (cable supplied)
o
0 to 50 C (32 to 122
80% Relative Humidity max.
Eight (8) 'AA' 1.5VDC batteries or AC 9V power adapter
Meter: 270 mA DC; Clamp: 22 mA DC
Clamp can accommodate up to 50 mm (2.0") diameter
Meter: 1010g (2.2 lbs.) (with batteries); Clamp: 500g (1.1lbs)
Meter: 225 X 125 X 64 mm (8.86 X 4.92 X 2.52")
Optional Clamp: 210 X 64 X 33mm (8.3 X 2.5 X 1.3")
Optional Clamp Jaw: 86 mm (3.4") Outer diameter
Instruction manual
Batteries
SD card (4G)
(45 to 65Hz; 23±5°C)
Range
10.0V to 600.0V
28.2V to 1.697kV
0.2A to 6000A
2.828A to 16.97kA
0.00 to 1.00
-180° to 180°
45 to 65Hz
0.0 to 3.6MW
0.0 to 3.6MVA
0.0 to 3.6MVAR
0.0 to 3.6MWH
0.0 to 3.6MVAH
0.0 to 3.6MVARH
6
www. .com
o
F)
Resolution Accuracy*
0.1V ± (0.5% range + 3 digits)
0.1V to 1V ± (0.5% range + 30 digits)
0.001A to 1 A ± (0.5% range + 5 digits)*
0.001A to 10 A ± (0.5% range + 30 digits)*
0.01 ± 0.04
0.1° ± 1°*
0.1Hz 0.1Hz
0.001k to 0.001M ± (1% range+8 digits)*
0.001k to 0.001M ± (1% range+8 digits)*
