IPD-SM5 Series
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for optimum audio
performance, installer must follow all directions issued by SoundTube Entertainment.
Haut-parleurs SoundTube doivent être installés par un installateur / contracor de l'audio professionnel. Par mesure de
sécurité et pour des performances audio optimales, l'installateur doit suivre toutes les directives émises par SoundTube
Entertainment.
IPD-SM500i-II
1.913.663.5600
Clamp Knob
©2016 SoundTube Entertainment, Inc. All rights reserved. PM INS-IPD-SM5 rev 5.26.16
Warning
Do not spec or install speaker near support beam, ventilation duct or other
structure that may interfere with speaker function or dispersion.
Ne spéci ez pas ou installer haut-parleur près de poutre de support, une
conduite d'aération ou une autre structure qui pourrait interférer avec la fonction
haut-parleur ou de dispersion.
|
|
855. 663.5600
www.soundtube.com
Mounting Bracket
Box Contents
1 Speaker
1 Mounting bracket
1 Safety cable
1 Safety cable anchor screws
1 Grille-mounted tap switch cover
1 Allen hex key
Advertisement
Table of Contents
Related Manuals for SoundTube IPD-SM5 Series
Summary of Contents for SoundTube IPD-SM5 Series
- Page 1 Warning Warning SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for optimum audio Do not spec or install speaker near support beam, ventilation duct or other performance, installer must follow all directions issued by SoundTube Entertainment.
- Page 2 Contact point. SoundTube for questions about installations requiring local power. 5. Line up bracket ribs with 6. Firmly grip speaker and pull it 7. Make sure knob is loose, and 8.
