IPD-SM-EZ
Box contents
1 Speaker
1 U-bracket
2 U-bracket screws
2 Screw caps
1 Allen wrench
1 Back plate
1 Port plug
1 Safety cable
1 Strain relief water tight gland
Safety cable
Strain relief water tight gland
U- bracket
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Series
Install Instructions For:
IPD-SM52-EZ and IPD-SM82-EZ
Back plate
Screw cap
1.435.647.9555
© 2019 SoundTube Entertainment, Inc. All rights reserved. PN IPD-INS-SM-EZ
Warning
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
U-bracket screw
|
|
800.647.TUBE
www.soundtube.com
Rev 07-11-2019
