EN-200
1080p AVC Low Latency Encoder
Includes modulator version - IF/LB/10M
USER GUIDE
3.00.29

Advertisement

Table of Contents
loading

Related Manuals for Adtec EN-200

Summary of Contents for Adtec EN-200

  • Page 1 EN-200 1080p AVC Low Latency Encoder Includes modulator version - IF/LB/10M USER GUIDE 3.00.29...

  • Page 2: Table Of Contents

    Table of Contents  Table of Contents Trademarks & Copyrights Electrical Device Compliance Notices Safety Warnings and Cautions Compliance Notices Industry Canada European Union EMC Directive Conformance Statement Chapter 1 - Getting Started Front Panel Front Panel LCD Quick Views Transport LED Indicators Audio Encode Indicators System Indicators Controls...
  • Page 3 How to Use ASI-Receive Mode How to Use ASI Remux EN-XX ASI Remux with Manual PID Mapping How to setup a Zixi IP stream on the Adtec Encoders Chapter 5 - Appendix Appendix A - GNU General Public License Appendix B - Technical Specifications...

  • Page 4: Trademarks & Copyrights

    Trademarks & Copyrights  Copyright:​ (c) 2016 Adtec Digital. All rights reserved. This document may not, in whole or in part, be copied, photocopied, reproduced and translated, or reduced to any electronic medium or machine-readable form without prior written consent from Adtec Digital.

  • Page 5: Electrical Device Compliance Notices

    Electrical Device Compliance Notices  Safety Warnings and Cautions  For your safety and the proper operation of the device: This unit must be installed and serviced by suitably qualified personnel only. ● Do not break the warranty seals on the device or open the lid. Only approved service ●...

  • Page 6: Industry Canada

    Consult the dealer or an experienced radio/TV technician for help. ● Warning: Changes or modifications to this device not expressly approved by Adtec Digital could void the user’s authority to operate the equipment. Industry Canada  This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations.

  • Page 7: Chapter 1 - Getting Started

    Chapter 1 - Getting Started  Front Panel  The Function Buttons and Directional Keypad of the EN-200 are used to configure and monitor the signal input and output of the device. Front Panel LCD Quick Views  There are several Quick Views that can be accessed via the front panel LCD by pressing the up and down arrows.
  • Page 8 4) ​ A udio Status: ​ T his quick view displays the Audio Codec type, Encode or Pass Through Rate, Encode or Passthrough mode. 5) ​ A udio PIDS: ​ T his quick view displays the Audio PIDs for all 8 pairs of audio. 6) ​...

  • Page 9: Transport Led Indicators

    On - Device is encoding. 3/2/1F Off - Low, Normal, or Long Latency On - 3 Frame, 2 Frame, or 1 Frame Latency (Requires Adtec RD-7x Decoder) 4:2:2 Off - Encoding chroma type 4:2:0. On - Encoding chroma type 4:2:2.

  • Page 10: System Indicators

    System Indicators  Indicator Function Alarm Off - No system alarms. On - System alarm. (Typically NTP alarm) BISS Off - Service is not encrypted “Clear - Free to air” On - Service is Encrypted “Cyphed - Selected BISS mode” Link Off - No network detected On - Network communication active Busy...

  • Page 11: Modulator Lineup

    Modulator Lineup  This feature enables the operator to quickly view and/or configure select modulator RF output parameters. The parameters available in this menu are; 1. Carrier Mode: [ PURE_CARRIER or MODULATED] 2. Transmit: [ ENABLED or DISABLED] 3. Output Power: [ in 0.5dB increments ] 4.

  • Page 12: Front Panel Menu Structure

    Front Panel Menu Structure  1. Services Menu  Item Function Options Transport Mux Rate is the total transport 1000000 - 150000000 TS Mux stream rate. Use this number to match total Rate circuit throughput note: The actual lower limit is configuration dependent. The Adaptive Bit-rate mode allows the ABR Mode encoder to adjust TMR and Video bit-rate...
  • Page 13 DVB - includes PMT, PAT, NIT and SDT tables DVB SDT ONLY MPEG - includes PAT and PMT tables MPEG ATSC - includes PAT, PMT, VCT, RRT, MGT, and STT tables DVB SDT ONLY - includes PMT, PAT, and SDT tables Routes a external ASI signal from the HD/SDI input in the place of the internally encoded...

  • Page 14: Rf Tx Menu

    2. RF Tx Menu  Note: This menu is dynamic. It will only appear if you unit has factory installed modulator option. Item Function Options Allows the operator to enable or Disable Transmit disable the Main RF output. If Enable Transmit is enabled and any value for Type, Frequency, Rolloff, Symbol Rate, or Interface Rate is changed, then Transmit will be...
  • Page 15 (Block Upconverter), and ​ m ay differ ​ from the value set in here. Read Only - DVB Modulator output The monitor output frequency for the Frequency frequency EN-200 IF is fixed at 1.080GHz. The...
  • Page 16 Power the output power of the main RF -30 to +5dBm IF output port. The monitor output power level for the EN-200 IF and L-Band is fixed at -45dBm. Power is defined as the composite power referenced to an un-modulated (Pure Carrier) carrier.
  • Page 17 data throughput is reduced by approximately 3.0%. 2.12 The Rate Priority control allows the Symbol Rate Priority operator to designate which rate Interface will be kept constant. When the Symbol Rate is entered and Rate Priority is Symbol, the symbol rate is held constant and the Interface rate is calculated.
  • Page 18 functionality the setting will read “N/A” 2.18 Scrambles all of the PLFRAMES The PLS signature assumes values in PHYSICAL except for their header. the range 0, 262141 LAYER SCRAMBLER This feature enables the operator Carrier Mode: MODULATOR to quickly view and/or configure PURE_CARRIER or MODULATED LINEUP select modulator RF output...

  • Page 19: Ip Tx Menu

    3. IP Tx Menu  Note: this is a parallel menu. It has four index. Use the left or right arrows to navigate to desired index. Item Function Options Enables IP Egress. Mode Send Switches from UDP/RTP, TCP, UDP/RTP IP Tx Mode RTMP, and Zixi Feeder Note:​...
  • Page 20 Forward Edge Correction; selects FEC Mode on/off. When selected, sends two FEC RTP streams in addition to a MAXBURST source RTP stream enabling a BURST receiver to reconstruct missing LOWLATENCY packets in the source stream. affects the maximum burst 4-20 FEC L packet loss that can be recovered...

  • Page 21: Video Menu

    4. Video Menu Item Function Options Allows the operator to select Input which input the video will be COMPOSITE sourced from. OPTICAL Allows the operator to force the AUTO SDI Mode SDI receiver into a specified mode. HD1.4G HD3G SD480i SD576i HD1.4G 720p HD1.4G 720p 50...
  • Page 22 are not dynamic. They take SD Optical) effect at the start of the next 700000 - 15000000 bits/sec (0.7 - encode session. 15 Mb/s) In high definition encoding mode. (input is HD/SDI, or HD Optical) 1500000 - 60000000 bits/sec (1.5 - 80 Mb/s) *If video autofill is enabled, this value will change based on other...
  • Page 23 4.12 The user can select encoder Fault Mode behavior during video loss. The BARS encoder can stop encoding, BARSTONES encode black, or generate a BARSOVERLAY combination of Black, Bars, BARSTONESOVERLAY Tones and Service ID. 4.13 Allows the operator to select 480I59.94 Fault Resolution what resolution to encode at...

  • Page 24: Audio Menu

    GOP Size two full image frames (I-Frames) keypad in a GOP Structure. range = 1-30 4.19 Enables multiple ADTEC Encoders 3-D Sync Mode to be synchronized. One unit is GENERIC MASTER designated as 'master' which is MASTER GROUP 1 - 9...
  • Page 25 Defines the type of audio to DD = Dolby Digital AC3 Type encode or pass. MU = Musicam Layer II DE = Dolby E LP = Linear PCM DD-06 = Dolby Digital, PMT stream type 0x06 MU-04 = Musicam Layer II, PMT stream type 0x04 The Audio Rate is the bitrate for user-defined using the numeric...

  • Page 26: Pids Menu

    special IFB receiver or manual PID selection with a standard IRD. Note: There is no PID reference in the PMT for this functionality. It is considered a ghost PID. It is also not lip-sync aligned with video. 5.12 Allows the operator to route SDI Pair embedded audio from SDI input to the specified audio encoder.

  • Page 27: Vbi Menu

    Programs periodically provide a Program Clock user-defined using PCR PID Reference, or PCR, on one of the PIDs in the the numeric keypad program. This is also known as the master clock. The PCR PID identifies the packets which contain PCR adaptation fields.

  • Page 28: Profile Menu

    8. Profile Menu  Command Function Displays the last profile loaded Last Loaded Profile The select submenu lists all stored profiles and allows loading Select The save submenu saves a profile with a user designated name Save The delete submenu deletes a profile from the available list DELETE  ...

  • Page 29: System Menu

    10. System Menu  10.1 Login  Units ship with the front panel logged in by default. If you become logged out and are prompted for a password, use the following key sequence for access. Action Press <Select> Press <Up> arrow Press <Select> Press <Enter>...

  • Page 30: Time Sub Menu

    10.3.2 Defines the unit relative to the user-defined using the numeric IP 1 Mask rest of your network. keypad Default is 255.255.255.0 10.3.3 The Dynamic Host Configuration On (finds own DHCP Address) IP 1 DHCP Protocol allows your device to Off (defaults to last entered IP self-locate network Ethernet Address)

  • Page 31: Alarm Menu

    CLEAR feature. We support SNMPv2c version. 10.7.2 The Simple Network user-defined Read-only Management Protocol (SNMP) community Read-Only Password. Default Value: "adtec" 10.7.3 The Simple Network user-defined Read-write Management Protocol (SNMP) community Read-Write Password. Default Value: "none" 10.7.4 The Simple Network...

  • Page 32: Feature Sub Menu

    Item Function Options Com2 Settings RS-232 terminal monitor for 115200 8 1 NONE communicating with the 57600 8 1 NONE internal host motherboard for 38400 8 1 NONE diagnostics. 19200 8 1 NONE 9600 8 1 NONE Default is 38400 8 1 None  ...

  • Page 33: Backlight Dim Delay

    10.12 Backlight Dim Delay  Action Press <Select> Using the <Up> and <Down> arrows, select the value you wish. Press <Enter> to save your selection    ...

  • Page 34: Back Panel

    Back Panel  Connector Description Power 1 & 2 Redundant AC Power, Standard 3 pin computer power plug (Auto range 70-240 VAC Input) (A) L-Band Out RF output, 50 Ohm BNC L-Band Model: Frequency range 950 MHz to 1.750 GHz, Power Level -35 to +5 dBm (B) Monitor RF output, 50 Ohm BNC...

  • Page 35: Gpio And Parport Information

    Analog Audio In Stereo Pairs 1 and 2 (600 Ohm Balanced) SFP slot used for single channel optical receiver module GPIO and Parport information  The GPIO port allows encoder stop / start control and TTL voltage output for monitoring systems. TTL pin behavior by default is HI (3V) when encoding and LO (0V) when not encoding.

  • Page 36: Parport Pinout

    Parport Pinout  Designation Function No Connect Data bit 3 ( input ) Data bit 2 ( input ) Data bit 1 ( input ) Data bit 0 ( input ) No Connect 5VDC +5V DC ground No Connect...
  • Page 37 Safari Chrome Ethernet Access  To begin, you will need to connect to your EN-200 via ethernet directly, or by adding the EN-200 to your local area network.The default address for all Adtec devices is 192.168.10.48. To connect directly to the device, make sure that your computer and the device have IP addresses within the same IP class range (ex.
  • Page 38 You will be prompted for a username and password. The default username is ‘adtec’. The default password is ‘none’. The left-hand panel of the application will report current status in real-time while the right panel tabs will allow you to configure your device.
  • Page 39 When prompted for a username, enter adtec. When prompted for a password, enter none. Once you see "User 'adtec' connected", the session is open and you may issue API commands to the unit. To extract and select into the new firmware version you have uploaded, issue the following commands.
  • Page 40 Chapter 4 - Operational How-To’s  How to Use Vertical Interval Time Code  Vertical Interval Time Code (VITC) is typically used in transmissions that require time code from the originating source to be preserved. It was originally developed for analog television recording systems, but has new standards for transmitting in digital systems (SMPTE-12M-1 / SMPTE-12M-2).
  • Page 41 ( LPCM ) from an embedded SDI or AES input passed into the egress transport stream ( IP, RF, ASI ). The EN-200 supports four passthru audios on the first four audio inputs. The SDI Matrix and ASI Transport Stream PID configurations allow for custom configurations if required.
  • Page 42 To enable Audio passthru for Audio 1: Step Action On the​ A udio -> Audio 1 in the Web GUI Control Application, configure the "Audio ​ Mode" for <PASSTHRU>. Configure the “Audio Input” for the desired input <AES> or <SDI>. note: If using SDI, select the proper audio pair from the SDI audio matrix.
  • Page 43 Typically, SDI video should be run through a frame synchronizer that is utilizing the same reference as the DE encoder. The Adtec encoder preserves audio and video timing as it is presented. If the audio timing does not match video timing at the inputs, there will be potential line placement errors and/or CRC errors seen on a decoder.
  • Page 44 Understanding Auto Transport Mux Rate  Auto Transport Mux Rate (TMR) is a feature of Adtec EN-Series built with the optional modulator. This feature will automatically configure the overall data rate of the encoder (its TMR;Transport Mux Rate), based upon its Modulator configuration. In other words, when the modulator Transmit configuration is set to 'ENABLED', the encoder’s TMR becomes the...
  • Page 45 The ASI input rate must be configured / viewed from the device feeding the EN unit. The third mode can be used by DISABLING modulator transmit. To enable your Adtec EN-series device for ASI Receive Mode, follow the following steps: Step Action On the rear panel of the device, connect your ASI cable to the "ASI-IN"...
  • Page 47 How to Use ASI Remux  Terminology: “ASI Remux” refers to the ability for an Adtec EN to accept a Transport Stream (TS) via ASI input, and multiplex the incoming service or services with it’s locally encoded service. The results is that the transport stream output becomes a MPTS containing the services from the ASI input in addition to to the locally encoded service.
  • Page 48 PMT - Program Map Table. This MPEG-2 table specifies PID values for components of programs. The Adtec EN-3X and EN-100 encoders have an ASI input available for the ASI remux feature. Further information can be read about ASI Remux in the ASI Remux article. In some cases, users may want to add custom PID’s from third party generators, such as a DVB Subtitles, into...
  • Page 49 PMT must be modified. A wiring diagram and sample PMT view can be seen in the drawing below. In the example above, a raw PID was sent into the system with no program association. The EN modified the main program PMT, Program 1, to add an additional DVB Subtitle PID entry. As EN encoders do not perform PID conflict resolution at this time, the PID’s inserted into the system should not conflict with other PID’s utilized by the EN-31.
  • Page 50 In the DVB Subtitle example, the PID is 135, DVB Subtitles use stream type 0x06 and a sample DVB descriptor with italian language is 52010259086974611000020002. The user will then need to map the entry into the associated PMT by visiting the Manual PID Mapping tab.
  • Page 51 ISO_IEC_11172_VIDEO1 ISO_IEC_13818_VIDEO MPEG1_Layer2 MPEG2_Part3 ISO_IEC_13818_PRIVATE ISO_IEC_13818_PES_PRIVATE DVB_AC3_AUDIO ISO_IEC_13522_MHEG DSM_CC ITU_T_REC_H222_1 ISO_IEC_13818_6_Type_A ISO_IEC_13818_6_Type_B ISO_IEC_13818_6_Type_C ISO_IEC_13818_6_Type_D ISO_IEC_13818_1_Aux ISO_IEC_13818_7_AUDIO_ADTS H264_VIDEO AVC_VIDEO DCII_VIDEO DOLBY_AC3 DCII_SUBTITLES DVB Specification for Service Information (SI) in DVB systems. Descriptor information can be reviewed here.
  • Page 52 How to setup a Zixi IP stream on the Adtec Encoders  The Zixi technology can be used to enhance the stability of an IP stream when the network is not in a controlled environment. The use of FEC and latency allows the receiver to request any missing packets and the encoder to resend as needed.
  • Page 53     allow a higher overall bitrate, but could lead to less stability depending on Latency used.
  • Page 54 Chapter 5 - Appendix  Appendix A - GNU General Public License  Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
  • Page 55 fee. 2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these conditions: a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change.
  • Page 56 conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License.
  • Page 57 most effectively convey the exclusion of warranty; and each file should have at least the "copyright" line and a pointer to where the full notice is found. <one line to give the program's name and a brief idea of what it does.> Copyright (C) <year> <name of author> This program is free software;...
  • Page 58 Appendix B - Technical Specifications  Base Model (EN200)  Inputs SD-SDI / HD-SDI / 3G-SDI Use: Video & Audio input Standard: SD - SMPTE 259M-C - 270Mbit/s with embedded audio per SMPTE 272M A, B, and C. HD - SMPTE 292M - 1.485Gbit/s with embedded audio per SMPTE 299M. 3G-SDI Level A and Level B. Connector: BNC (75 Ohm).
  • Page 59 Outputs DVB-ASI Use: Transport Stream output. Physical interface 150Mbit/s. ASI concurrent with TSoIP (GigE) and RF Tx (DVBS/S2). Standard: ISO13818-1 MPEG 2 Transport Stream per EN 50083-9:1997 (188 byte only) Connector: Three BNC (75 Ohm) GigE Transport Over IP (TSoIP) Use: Transport Stream Output, but may also be used for control.
  • Page 60 Connector: DB9 Male GPIO Port Use: GPIO DB9 parallel port used for Encode, Stop, Status/Alarms, and SCTE 35 generation Connector: DB9 Male Video H.264 MPEG-4 SD (ITU-T H.264 ISO 14496-10) Format: Standard Definition D1 NTSC 29.97 fps (480i59.94) and PAL 25 fps video (576i50) Level 3.0 to Level 3.2 4:2:0 Chroma: High Profile, Level 3.0 4:2:2 Chroma: High Profile, Level 3.0*...
  • Page 61 Audio Passthrough - Dolby E 5.1/2.0/1.0, AC-3, LPCM, Linear Acoustic Audio Signal Generation - MPEG 1 Layer 2 audio tones user selectable frequency per pair from 440 hz to 2.5Khz. Group L/R mute or Pair L/R mute. No audio inputs are required to generate audio tones. Transport Table Generation MPEG Program Specific Information (PSI) table compliance: PAT / CAT / PMT...
  • Page 62 Physical and Operational Physical / Environmental 1 RU chassis ( 19” X 18” X 1.65” / 482mm x 457mm x 44mm ) Weight – 9-14lbs. Dependent on installed options Power Input Voltage: Redundant auto switching dual 100 - 240 VAC 50/60Hz (Standard) Power Consumption Start-up: 46 Watts Operational: 45 Watts ( base consumption, actual consumption depends on installed options )
  • Page 63 IF, L-Band Modulator + 10MHz Requires factory installation note*: software keys are required to unlock full hardware support. Compliant standards supported: DVB-S (EN 300421), DVB-S2 (EN 302307) and DVB-S2X (DVB-S2 Extensions) Modulation Scheme Support: QPSK / 8PSK / 16APSK / 32APSK DVB-S QPSK FEC rates: 1/2, 2/3, 3/4, 5/6, 7/8 DVB-S2 QPSK FEC rates: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 DVB-S2 8PSK FEC rates: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10...
  • Page 64 Appendix C - DB15-M Analog audio input pinout:  Adtec sells an analog audio input cable as part of our accessory offerings. If you prefer to make your own cable, below is the pinout. Signal Channel 0 left + No Connection...
  • Page 65 All inquiries will be processed in the order in which they are received and by the criteria outlined in the Call Response Order. Inquiries and inquiry responses made after 5:00 PM (CST) weekdays, Saturday, Sunday or on an Adtec-recognized holiday will be processed the next business day in the order received.
  • Page 66 Include the approximate time and day the problem occurred, the spot ID of the material being inserted and what the operator reported about the incident. It is also helpful to note any recent changes to the system. More information is always better than too little information.
  • Page 67 *Available for up to three years after purchase for Adtec manufactured products only **Excludes equipment that has been subject to misuse, negligence, or accident All SLAs are subject to terms and conditions of sale. For details see adtecdigital.com/sales/terms  ...
