BT7164
470MM (18.5") x 310MM (12.2") GLASS SHELF
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Glass Shelf
PLEASE KEEP THIS FOR FUTURE REFERENCE
COMPATIBLE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Sample Installations............................................................................................................................6
Product Dimensions............................................................................................................................7
B-Tech Contact Details.......................................................................................................................8
DESIGNED FOR USE WITH (sold separately):
B-TECH AUDIO VIDEO MOUNTS
FEATURES
●
●
●
●
●
CONTENTS
BT7151
www.btechavmounts.com
Designed for AV equipment up to 7.5kg (17lbs)
For single pole mounting
Shelf dimensions:
470mm (18.5") x 310mm (12.2")
10mm (0.4") thick tempered safety glass
Meets British Standard BS6206
CAUTION!! GLASS
This item contains glass -
Handle with care to avoid
damage or injury
BT7161
Advertisement
Related Manuals for B-Tech BT7164
Summary of Contents for B-Tech BT7164
-
Page 1: Table Of Contents
This item contains glass - Handle with care to avoid damage or injury COMPATIBLE CONTENTS Installation Safety Notes........................2 Parts List.............................4 Sample Installations..........................6 Product Dimensions..........................7 B-Tech Contact Details........................8 DESIGNED FOR USE WITH (sold separately): BT7161 BT7151 B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT7164 PARTS LIST Suitable for loads up to 7.5kg (17lbs) - Page 5 PART NAME GLASS SHELF 470mm x 310mm PLEASE KEEP THIS FOR FUTURE REFERENCE...
-
Page 6: Sample Installations
60mm (2.4") pole. Using 50mm (2") pole. Ø Ø 60mm (2.4") 50mm (2") pole (sold pole (sold BT7151 BT7161 separately) separately) (sold (sold separately) separately) BT4005, BT4011, BT4015, BT7325/26 & BT7850 BT4020, BT7504 & BT8504 (sold separately) (sold separately) BT7161 BT7164 BT7504... -
Page 7: Product Dimensions
BT7164 PRODUCT DIMENSIONS 10mm 0.4" 470mm 18.5" TEMPERED GLASS: Meets BS6206 THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 8: B-Tech Contact Details
©2011 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech & Better By Design are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
