Vertical Elements Assembly - DX Engineering DXE-7580FS-VA Manual

QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
8
4
2
2
2
2
16
8
2
3
3
3
1
2
1
1
Note: This antenna system is normally shipped in several boxes. The hardware parts maybe in
more than one box. The part lists listed above are arranged for ease of assembly.

Vertical Elements Assembly

4.00" OD x 71.75" long, .25" wall, 5 drilled holes
3.50" OD x 71.75" long, .25" wall, 8 drilled holes
3.00" OD x 72" long, .120" wall, 8 drilled holes
2.75" OD x 48" long, .120 wall, 4 drilled holes
2.75" OD x 48" long, .120 wall, 8 drilled holes
2.5" OD x 72" long, .120 wall, 8 drilled holes
2.25" OD x 72" long, .120 wall, 8 drilled holes
2" OD x 72" long, .120 wall, 4 drilled holes one end, slits one end
1.75" OD x 72" long, .120 wall, slits on one end
1.5" OD x 72" long, .120 wall, slits on both ends
1.25" OD x 36" long, .058 wall, slits on one end
1.125" OD x 36" long, .058 wall, slits on one end
1" OD x 36" long, .058 wall, slits on one end
0.875" OD x 36" long, .058 wall, slits on one end
0.75" OD x 36" long, .058 wall, slits on one end
0.625" OD x 36" long, .058 wall, slits on one end
0.50" OD x 36" long, .058 wall, slits on one end
5/16-18 x 5" Stainless Steel Hex Head Cap Screw
5/16-18 x 4-1/4" Stainless Steel Hex Head Cap Screw
5/16" Stainless Steel Flat Washer
5/16-18 Stainless Steel Nyloc Hex Nut
1/4-20 x 3-1/2" Stainless Steel Hex Head Cap Screw
1/4-20 x 3-1/4" Stainless Steel Hex Head Cap Screw
1/4-20 x 3" Stainless Steel Hex Head Cap Screw
1/4-20 x 2-3/4" Stainless Steel Hex Head Cap Screw
1/4" Stainless Steel Flat Washer
1/4-20 Stainless Steel Nyloc Hex Nut
DXE-ECL-24SS Stainless Steel Element Clamp - 2"
DXE-ECL-20SS Stainless Steel Element Clamp - 1-3/4"
DXE-ECL-16SS Stainless Steel Element Clamp - 1-1/2"
DXE-ECL-12SS Stainless Steel Element Clamp - 1-1/8" to 1-1/4"
DXE-ECL-10SS Stainless Steel Element Clamp - 1"
DXE-ECL-060 Stainless Steel Element Clamp - 3/4" to 7/8"
DXE-ECL-040 Stainless Steel Element Clamp - 5/8"
Black Vinyl Cap for 1/2" OD Tube
- 34 -
Description
