DXE-7580-VA-3 Parts List
Pivot Base Assembly - US Patent No. 8,130,168
QTY
1
1
2
1
6
1
1
2
1
2
2
3
5
42
34
34
8
4
4
8
2
4
2
2

Optional DXE-VRW-1 Manual Winch Assembly

QTY
1
3
8
4
1
1
QTY
1
2
2
3
4" Base Side Bottom Hinge
4" Antenna Side Bottom Hinge
4" Bottom Hinge Bushing
® Insulator 10" x 1/2" x 29.625"
Heavy Duty Extren
Saddle Backing Plate 1.5" x .375" x 8"
4" Antenna Pivot Hook Mount
4" Pivot Base Winch Mount
Pivot Base Plate Bracket
4" Pivot Base Lock Plate
Backing Plate
4" x 3/8" x 5.563" Stainless Steel U-Bolt *
4" x 3/8" x 6.813" Stainless Steel U-Bolt *
4" Cast Saddle Clamp *
3/8" Flat Washer *
3/8" Split Lock Washer *
3/8"-16 Nut *
3/8"-16 x 1.375" Long, Hex Head Cap Screw
3" Cast Saddle *
3" x 3/8" x 5.25" Stainless Steel U-Bolt *
3/8"-16 x 1-3/4" Long Stainless Steel Square Neck Carriage Bolt
1/2"-13 x 1-3/4" Long Stainless Steel Hex Head Cap Screw
1/2" x 1-1/4" Stainless Steel Washer
1/2" Stainless Steel Lock Washer
1/2"-13 Stainless Steel Nut
* Note: The U-Bolts and their hardware may be packaged separately
1500 Pound Exposed Gear Hand Winch with Brake
3/8-16 x 1-3/8" long Stainless Steel Hex Bolt
3/8"-16 Stainless Steel Flat Washer
3/8-16 Stainless Steel Nyloc Nut
Custom Polyester web strap with Hook, 2" x 15 Ft
3/8-16 x 3-1/2" long Grade 8 Hex Head Bolt

Feedpoint Hardware

1/4-20 x 1" Stainless Steel Hex Head Cap Screw
1/4" Stainless Steel Flat Washer
1/4-20 Stainless Steel Hex Nut
1/4" Stainless Steel External Star Washer
Description
Description
Description
