Char-Broil BIG EASY 4638213 Parts List

Parts List - Model 4638213
Key Qty. Description . . . . . . . . . . Part # Key Qty. Description
A 2 Tent Frame . . . . . . . . . 4151014 CC 1 Hardware, Cart Assy. . . . 4254008
DD 1 Hardware, Shelf . . . . . . . 4254010
B 1 Warming Rack . . . . . . 4152043
EE 1 Right Leg . . . . . . . . . . . . 4502161
C 1 Cooking Grid, 12" . . . . 4152045
FF 2 Burner. . . . . . . . . . . . . . . 5068016
D 1 Cooking Grid, 15" . . . . 4152046
GG 1 Grease Clip. . . . . . . . . . . 5156607
E 1 Handle . . . . . . . . . . . . 4154488
F 2 Wheel . . . . . . . . . . . . . 4156957
G 1 LP Tank . . . . . . . . . . . . 4158015
H 2 Burner Tent . . . . . . . . . 4500226
I 1 Upper Panel . . . . . . . . 4502072
J 1 Tank Support. . . . . . . . 4502098
K 1 Tank Retainer . . . . . . . 4502113
L 2 10x1/2" Screw, . 4080043
Self-tap
M 2 Pivot Pin . . . . . . . . . . . 4080066
N 2 3/16 Pal Nut . . . . . . . . 4153096
O 1 Ignitor Wire . . . . . . . . . 4153184
P 2 Leg Extender . . . . . . . 4154516
Q 2 3/4" Hitch Pin . . . . . . . 4156515
R 1 Carry-over Tube . . . . . 4500227
S 1 Heat Shield . . . . . . . . . 5501038
T 1 Left Leg. . . . . . . . . . . . 4502194
U 1 Console Assembly . . . 4530058
V 1 Ignitor . . . . . . . . . . . . . 4153713
W 1 Grill Bottom . . . . . . . . . 4580316
X 1 Right Shelf Assembly . 4520011
Y 1 Left Shelf Assembly . . 4520012
Z 1 Grill Top. . . . . . . . . . . . 4580144
AA 2 Control Knob. . . . . . . . 4154507
BB 1 Logo Plate. . . . . . . . . . 4157147
. . . . . . . . . . Part
BB
E
C
Y
T
GG
P
Z
B
H
O
A
D
N N
R
FF
S
X
W
Q
U
Q
L
L
V
M M
K
AA
EE
I
F
J
F
G
4638213 / 1–4165041 (02-11-02)
4638213
ASSEMBLY MANUAL
THIS GRILL IS FOR
OUTDOOR USE ONLY
CAUTION: Read and follow all safety
statements, assembly instructions,
and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER: Leave
these instructions with consumer.
CONSUMER: Keep this manual for
future reference.
WARNING
!
Failure to follow all manufacturer's
instructions could result in serious
personal injury and/or property
damage.
CAUTION
!
Some parts may contain sharp edges
– especially as noted in the manual!
Wear protective gloves if necessary.
If you have any questions or need
assistance during assembly, please
call 1-800-241-7548.
Visit us on the web at:
www.charbroil.com
