Summary of Contents for Char-Broil 463230512

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Charbroil 463230512 Owner's Manual Shop genuine replacement parts for Charbroil 463230512 Find Your Charbroil Grill Parts - Select From 3621 Models -------- Manual continues below part list --------...
  • Page 2 Available Replacement Parts for Charbroil 463230512 01800 control knob G350-0024-W2 Fixed Caster. Fits multiple RED, Quantum G416-0015-W1 Grease Pan. Measures approximately: 7.7" G508-0039-W1 Match Holder And Chain. 05592 burner, cross-over, 6.375 x 0.8125, Char g409-0030-w1 Button For Electronic Module. Measures a...
  • Page 3 68764 grid, ci, 16.875 x 37.25; Chb G350-0026-W1 Caster Pin. G350-0023-W2 Caster Locking. Fits Commercial Series, 04432 electrode; Kenmore, Nexgrill, Tera Gear G401-0053-W1 Fixed Door Pin. G439-0036-W2 Door Pin Spring. G430-0042-W2 Electrode, F/ Sideburner. Measures appro G651-0009-W1 Handle For Door. Stainless steel grill d G430-0022-W2 Temperature Gauge G65103-B001-W1B...
  • Page 4 ASSEMBLY • Place bottom shelf between side panels with cut out hole for LP cylinder on left . Attach to left and right side panels with (4) 1/4-20x2-3/8” machine screws and 1/4-20 flange nuts at front, and (2) 1/4-20x2-3/8” machine screws and 1/4-20 flange nuts at rear.
  • Page 5 • Hook tank exclusion wire onto the metal taps on lower back panel, attach other ends to bottom shelf with (2) #8x3/8” sheet metal screws. Lower Back Panel #8x3/8" Sheet Metal Screws Qty. 2 Metal Tap • Place front door brace as shown. Attach to left and right side panels with (4) 1/4-20x2-3/8"...
  • Page 6 • Turn assembly upside down. • Insert Caster Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the legs until secure. Remove the Caster Pin and repeat for remaining casters. Make sure the two locking casters are secured at the rear and the non-locking casters are secured at the front.
  • Page 7 • This step requires two people to lift and position grill head onto cart. • Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging outside the cart. Attach with (2) 1/4-20x1/2” screws. Right side panel removed for clarity Grill Head 1/4 20x1/2"...
  • Page 8 • Attach towel bar to right side shelf with 1/4-20x1/2” Screws , 7mm lock washers and 7mm flat washers (A). • Hook side wall of shelf over support brackets on side of firebox (B). • Inside firebox attach right side shelf with (3) 7mm fire washers and 1/4-20x1/2” screws, as shown (C). At back of firebox, attach the right side shelf with (1) 7mm fire washer and 1/4-20x1/2”...
  • Page 9 • Hook side wall of sideburner shelf over support brackets on side of firebox (A). • Inside firebox attach sideburner shelf with (3) 7mm fire washers and 1/4-20x1/2” screws, as shown (B). At back of firebox, attach the sideburner shelf with (1) 7mm fire washer and 1/4-20x1/2” screw, as shown (A). •...
  • Page 10 • Attach sideburner bezel and valve with (2) #8x3/8” SS screws. (A). • Place sideburner into shelf. Make sure valve is inside sideburner tube. Attach sideburner with (1) wing nut (B). Hook venturi clip to sideburner tube and around manifold. Attach sideburner ignitor wire (C). •...
  • Page 11 • Attach handle to door with (4) #10-24x1/2” machine screws, 5mm flat washers and 5mm lock washers (A). • Insert hinge pin on bottom shelf into hole in door. Press upper hinge pin in front door brace, align hinge hole on top of door, and release hinge pin into door.
  • Page 12 • Place heat tents over tube burners by inserting tabs into slots in front of firebox. Opposite ends of heat tents rest on pins in back of firebox. NOTE: There is no heat tent over sear burner. Sear Burner • Place cooking grates onto grate rests.
  • Page 13 • Attach the heat shield to grease tray with (4) #8x3/8” sheet metal screws (A). • Place grease pan into grease tray, then place the tray into the cart (B). Heat Shield #8x3/8" Grease Tray Sheet Metal Screws Qty. 4 CAUTION Failure to install grease tray and grease pan will cause hot grease to...
  • Page 14: Troubleshooting

    DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. • Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 15: Electronic Ignition

    Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light ELECTRONIC IGNITION: using ignitor. • No spark, no ignition noise. • See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • See Section II of Electronic Ignition System. •...
  • Page 16: Troubleshooting - Electronic Ignition

    Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause Check Procedure Prevention/Solution SECTION I No sparks appear at • Battery not installed • Check battery orientation. • Install battery (make sure that “+” and “–” any electrodes when properly. connectors are oriented correctly, with “+” end up Electronic Ignition Button and “–”...
