© 2011 Char-Broil, LLC Columbus, GA 31902
PRODUCT GUIDE
MODEL 463622512
C-22G1CB
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Printed in China
See rating label on grill for serial number.
Assembly instructions © 2011
11/17/11 • G309-001-030801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 463622512 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil 463622512

Summary of Contents for Char-Broil 463622512

  • Page 1 PRODUCT GUIDE MODEL 463622512 C-22G1CB IMPORTANT: Fill out the product record information below. Serial Number See rating label on grill for serial number. Date Purchased For support and to register your grill, please visit us at www.charbroil.com If you have questions or need assistance during assembly, please call 1-800-241-7548.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DANGER For Your Safety ........2-3 If you smell gas: Grilling Guide.
  • Page 3 WARNING CAUTION CALIFORNIA PROPOSITION 65 Using pots larger than 6 quarts in capacity could exceed weight limit of the 1. Combustion by-products produced when using this product contain chemicals known to the State of side burner shelf California to cause cancer, birth defects, and other or side shelf, reproductive harm.

  • Page 4: Grilling Guide

    GRILLING GUIDE – Getting Started Temperature - Convective Grills ONLY. The temperature gauge in the hood of your new grill measures air temperature. The air temperature inside your grill will never First Time Use be as hot as the temperature at the cooking surface. Read your Assembly Manual and ensure the grill is put together properly.
  • Page 5 Rotisserie Cooking GRILLING GUIDE – Grilling 101 Rotisserie cooking is best for 'round' meat, such as large roasts, whole poultry, and pork. It generally requires an accessory motor Outdoor grilling is really quite simple. You'll succeed with and spit rod that allows the meat to be turned at a constant burgers, dogs, or steaks usually on your very first try.
  • Page 6 Wood Chips GRILLING GUIDE – Tips & Tricks For extra smoke flavor when grilling, try adding wood chips. Cooking on your new grill is a hands-on experience, and it is Soak the chips in water for approximately 30 minutes before recommended to remain outside with your grill while cooking.

  • Page 7: Grilling Guide

    Cooking surfaces: If a bristle brush is used to clean any of the GRILLING GUIDE – Cleaning Your Grill grill cooking surfaces, ensure no loose bristles remain on cooking Why Clean? surfaces prior to grilling. It is not recommended to clean cooking surfaces while grill is hot.

  • Page 8: Use And Care

    LP Cylinder USE AND CARE •The LP cylinder used with your grill must meet the following requirements: DANGER •Use LP cylinders only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. •...
  • Page 9 LP Cylinder Exchange Connecting Regulator to the LP Cylinder •Many retailers that sell grills offer you the option of replacing 1.LP cylinder must be properly secured onto grill. (Refer to your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.Turn all control knobs to the OFF position.
  • Page 10 Leak Testing Valves, Hose and Regulator 1.Turn all grill control knobs to OFF. 2.Be sure regulator is tightly connected to LP cylinder. 3.Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
  • Page 11 Safety Tips WARNING Before opening LP cylinder valve, check the coupling nut for tightness. When grill is not in use, turn off all control knobs and LP cylinder valve. For Safe Use of Your Grill and to Avoid Serious Never move grill while in operation or still hot. Injury: Use long-handled barbecue utensils and oven mitts to avoid •...
  • Page 12 Ignitor Lighting (continued) Burner Flame Check 8. For grills equipped with ELECTRONIC IGNITION at • Remove cooking grates and flame tamers. Light burners, rotate each burner: knobs from HI to LOW. You should see a smaller flame in Repeat steps 4 through 6 to light each burner. LOW position than seen on HI.

  • Page 13: Spider Alert

    3. Remove carryover tubes and burners. CAUTION Detach electrode from burner. NOTE: Removal/Detachment method will depend on the SPIDER ALERT! burner configuration. See different configurations in illustrations below. 5. Carefully lift each burner up and away from valve openings. We suggest three ways to clean the burner tubes. Use the one SPIDER AND WEBS easiest for you.

  • Page 14: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 15: Parts List

    PARTS LIST Qty Description Qty Description FIREBOX DOOR, NO HANDLE MAIN BURNER DOOR HANDLE ELECTRODE, F/ MAIN BURNER MAGNET ASSEMBLY CARRY OVER TUBE DOOR PIN, SPRING CONTROL PANEL, MAIN DOOR PIN, FIXED ELECTRONIC IGNITION MODULE BUTTON, F/ IGNITION MODULE NOT Pictured SHIELD, F/ ELECTRONIC IGNITION MODULE …...

  • Page 16: Parts Diagram

    PARTS DIAGRAM...

  • Page 17: Assembly

    ASSEMBLY Place bottom shelf upside down. Insert Caster Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Caster Pin and repeat for remaining casters. Make sure the two locking casters are secured at the rear and the non-locking casters are secured at the front.
  • Page 18 Attach upper door brace and back rail to cart side frames with #8x3/8” sheet metal screws. Upper Door Brace #8x3/8’’ Sheet Metal Screw Qty. 8 Back Rail Front Rear Attach handle to door with #10-24X3/8˝ machine screws, 5mm lock washers and 5mm flat washers. Insert hinge pin on bottom shelf into hole in door.
  • Page 19 Carefully lower the gill head onto the cart. Make sure the regulator hose is hanging inside the cart. Secure with 1/4-20X1/2'' machine screws as shown. 1/4-20X1/2'' Machine Screw Qty. 4 Hang side shelf assembly onto the pre-installed screws and bushings on side shelf brackets as shown. Insert 1/4-20X1/2'' Machine Screws and bushings through side shelf assembly and side shelf brackets.
  • Page 20 Place heat tents over burners by inserting tabs into slots in front of firebox. Opposite ends of heat tents rest on pins in back of firebox. Place cooking grates onto grate rests. Unscrew ignitor cap and place AAA battery into ignitor slot with positive end (+) facing outward. Replace ignitor cap onto ignitor.
  • Page 21 Insert ends of Warming Rack pivot wire into holes in sides of grill lid. Insert ends of Warming Rack leg wire into holes in sides of firebox. NOTE: Pivot and leg wires, running side-to-side, should be under wires running front-to-back. If pivot and leg wires are on top, Warming Rack is installed upside-down. Swing Away Pivot Wire Leg Wire...
  • Page 22 LP tank is sold separately. Use only with an OPD (over-fill protection device) equipped LP tank. Fill and leak-check before attaching to grill and regulator. See Use and Care section to correctly Leak Test and perform the Burner Flame Check. Place LP tank into hole in bottom shelf with tank collar opening facing to front of grill as shown.

  • Page 23: Troubleshooting

    DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. • Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 24 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light ELECTRONIC IGNITION: using ignitor. • No spark, no ignition noise. • See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • See Section II of Electronic Ignition System. •...

  • Page 25: Troubleshooting

    Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause Check Procedure Prevention/Solution SECTION I No sparks appear at • Battery not installed • Check battery orientation. • Install battery (make sure that “+” and “–” any electrodes when properly. connectors are oriented correctly, with “+” end up Electronic Ignition Button and “–”...
  • Page 26 NOTE...
