Introduction
This section provides an overview of the Texas Instruments (TI) TPA2013D1 audio amplifier evaluation
module (TPA2013D1EVM). It includes a brief description of the module and a list of EVM specifications.
1.1
Description
The TPA2013D1 is a 2.7-W Class-D amplifier with built-in boost converter. It drives up to 2.7 W (10% THD
+ N) into a 4-Ω speaker from low supply voltages.
The TPA2013D1 audio power amplifier evaluation module is a complete, stand-alone audio board. It
contains the TPA2013D1 QFN (RGP) Class-D audio power amplifier with an integrated boost converter.
All components and the evaluation module are Pb-Free.
1.2
TPA2013D1EVM Specifications
V
Supply voltage range
DD
I
Supply current
DD
Continuous output power per channel, 4 Ω, V
P
O
V
Audio Input Voltage
I
R
Minimum load impedance
L
SLOU194 - August 2007
Submit Documentation Feedback
Contents
...............................................................................................
.............................................................................................
.................................................................................................
List of Figures
...............................................................................................
.............................................................................................
..........................................................................................
List of Tables
......................................................................................................
.................................................................................................
= 3.6 V, V
DD
TPA2013D1EVM
= 5.5 V
CC
User's Guide
SLOU194 - August 2007
1
2
5
6
8
5
6
7
5
8
-0.3 V to 5.5 V
2 A Maximum
2.7 W
-0.3 V to V
+ 0.3 V
DD
4 Ω
TPA2013D1EVM
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments TPA2013D1
Summary of Contents for Texas Instruments TPA2013D1
-
Page 1: Table Of Contents
(TPA2013D1EVM). It includes a brief description of the module and a list of EVM specifications. Description The TPA2013D1 is a 2.7-W Class-D amplifier with built-in boost converter. It drives up to 2.7 W (10% THD + N) into a 4-Ω speaker from low supply voltages. - Page 2 2.1.3 Gain Control The TPA2013D1 has three gain settings: 2 V/V, 6 V/V, and 10 V/V. 1. Use jumper J13 to set the gain as 2 V/V, 6 V/V or 10 V/V. To achieve 2 V/V, place the jumper between heads 1 and 2;...
- Page 3 Working inductance decreases as inductor current increases. If the drop in working inductance is severe enough, it may cause the boost converter to become unstable, or cause the TPA2013D1 to reach its current limit at a lower output power than expected. Inductor vendors specify currents at which inductor values decrease by a specific percentage.
- Page 4 Increase the inductance to reduce the ripple current. Note that making the inductance too large prevents the boost converter from responding to fast load changes properly. Typical inductor values for the TPA2013D1 are 4.7 μH to 6.8 μH.
-
Page 5: Tpa2013D1Evm Schematic
All power levels are calculated at 1% THD unless otherwise noted All values listed are for ceramic capacitors. The correction factor of 2 is included in the values. TPA2013D1EVM Schematic VOUT+ OUT+ VCCFB VOUT+ GAIN TPA2013D1 VOUT+ AGND VOUT- VOUT- OUT- INPUT/GND Figure 1. TPA2013D1EVM Schematic SLOU194 –... -
Page 6: Tpa2013D1Evm Pcb Layers
www.ti.com TPA2013D1EVM PCB Layers TPA2013D1EVM PCB Layers Figure 2. TPA2013D1EVM – Top Layer Note: C4 has two separate pad sizes. One is for a 1210 ceramic capacitor, and the other is for a size "C" tantalum capacitor. Do not populate more than one at a time. TPA2013D1EVM SLOU194 –... -
Page 7: Tpa2013D1Evm - Bottom Layer
www.ti.com TPA2013D1EVM PCB Layers Figure 3. TPA2013D1EVM – Bottom Layer SLOU194 – August 2007 TPA2013D1EVM Submit Documentation Feedback... -
Page 8: Tpa2013D1Evm Parts List
LED, Green 0805 Lumen DIBI-Key S.L.-LXT0805GW 67-1553-1-ND LED, Yellow 0805 Lumen DIBI-Key S.L.-LXT0805YW 67-1554-1-ND TPA2013D1 RGP Texas Instruments TPA2013D1RGP MH1-MH4 Standoff, 5/8" length, #4-40, Brass/Zinc plate MH5-MH8 Screw, 1/2" length, #4-40, Brass/Zinc plate MH9-MH12 Washer, #4, Brass/Zinc plate Note: DNP = Do Not Place TPA2013D1EVM SLOU194 –... - Page 9 EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards.
- Page 10 TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products...
