- Page 1 TPA711 MSOP Audio Power Amplifier Evaluation Module User’s Guide 2001 Mixed-Signal Products SLOU027B...
- Page 2 IMPORTANT NOTICE Texas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue any product or service without notice, and advise customers to obtain the latest version of relevant information to verify, before placing orders, that information being relied on is current and complete. All products are sold subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those pertaining to warranty, patent infringement, and limitation of liability.
- Page 3 SLOU011) provides detailed information on the evaluation platform and its use with TI audio evaluation modules. TPA711 700-mW Low-Voltage Audio Power Amplifier (literature number SLOS230) This is the data sheet for the TPA711 audio amplifier integrated circuit. FCC Warning This equipment is intended for use in a laboratory test environment only.
-
Page 5: Table Of Contents
............Using The TPA711 MSOP EVM With The Plug-N-Play Evaluation Platform . - Page 6 ............2–2 Platform Jumper and Switch Settings for the TPA711 MSOP EVM ....
-
Page 7: Introduction
Chapter 1 Introduction This chapter provides an overview of the Texas Instruments (TI) TPA711 MSOP audio amplifier evaluation module (SLOP214). It includes a list of EVM features, a brief description of the module illustrated with a pictorial diagram, and a list of EVM specifications. -
Page 8: Feature Highlights
Feature Highlights 1.1 Feature Highlights The TI TPA711 MSOP audio amplifier evaluation module and the TI plug-n-play audio amplifier evaluation platform include the following features: TPA711 Low-Voltage Audio Power Amplifier Evaluation Module Single channel, bridge-tied load (BTL) 3.3-V and 5-V operation 700-mW output power into 8 Ω... -
Page 9: Description
SLOP214 TPA711 MSOP EVM † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB Single in-line header pins are mounted to the underside of the module circuit... - Page 10 Introduction...
-
Page 11: Quick Start
Chapter 2 Quick Start The steps in this chapter can be followed to quickly prepare the TPA711 MSOP audio amplifier EVM for use. Using the TPA711 MSOP EVM with the TI plug-n-play audio amplifier evaluation platform is a quick and easy way to connect power, signal and control inputs, and signal outputs to the EVM, using standard connectors. -
Page 12: Precautions
Precautions 2.1 Precautions Power Supply Input Polarity and Maximum Voltage Always ensure that the polarity and voltage of the external power connected to V power input connector J1, J2, and/or V power input connector J6 are correct. Overvoltage or reverse-polarity power applied to these terminals can open onboard soldered-in fuses and cause other damage to the platform, installed evaluation modules, and/or the power source. -
Page 13: Quick Start List For Platform
1) Ensure that all external power sources are set to OFF and that the platform power switch S1 is set to OFF. 2) Install a TPA711 MSOP module in platform sockets U3 and U4 for stereo operation (or a module in either U3 or U4 for single channel operation), taking care to align the module pins correctly. -
Page 14: Quick Start List For Stand-Alone
SLOP214 TPA711 MSOP EVM † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB Power supply 1) Ensure that all external power sources are set to OFF. -
Page 15: Details
Chapter 3 Details This chapter provides details on the TPA711 IC, the evaluation module, the steps in the Quick-Start List, additional application information, and a parts list for the TPA711 MSOP evaluation module. Topic Page Precautions .......... -
Page 16: Precautions
Precautions 3.1 Precautions Power Supply Input Polarity and Maximum Voltage Always ensure that the polarity and voltage of the external power connected to V power input connector J1, J2, and/or V power input connector J6 are correct. Overvoltage or reverse-polarity power applied to these terminals can open onboard soldered-in fuses and cause other damage to the platform, installed evaluation modules, and/or the power source. -
Page 17: The Tpa711 Msop Audio Amplifier Evaluation Module
INSTRUMENTS SLOP214 TPA711 MSOP EVM † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB Figure 3–3. TPA711 MSOP EVM Schematic Diagram 2.5 V to 5.5 V 10 µF... -
Page 18: Tpa711 Audio Amplifier Ic
3.2.1 TPA711 Audio Amplifier IC The TPA711 audio amplifier IC is a CMOS device intended primarily for bridge-tied load (BTL) operation in battery-powered applications. It is supplied in a very small surface-mount package and has been designed to operate from low supply voltages (between approximately 2.5 V and 5.5 V) and deliver up... - Page 19 3.2.4 Module Gain The TPA711 MSOP evaluation module has a set gain of –4 V/V. However, the gain can be adjusted to a maximum of –22 V/V by changing the value of resistor R3 (Figure 3–3). Use the following equation to determine value of R –...
-
Page 20: Using The Tpa711 Msop Evm With The Plug-N-Play Evaluation Platform
Using The TPA711 MSOP EVM With the Plug-N-Play Evaluation Platform 3.3 Using The TPA711 MSOP EVM With the Plug-N-Play Evaluation Platform The TPA711 MSOP audio amplifier evaluation module was designed to be used with the TI plug-n-play audio amplifier evaluation platform. It simply plugs into socket U3 or U4. -
Page 21: Platform Signal Routing And Outputs
The audio signal from the input jacks can be applied to the signal conditioning socket (U1) if an EVM is installed there, or socket U1 can be bypassed and the audio input signal applied directly to the inputs of the TPA711 power amplifiers. Switch S2 selects signal conditioning or bypasses it 3.3.2.2... -
Page 22: Mute/Mode And Polarity Control
Using The TPA711 MSOP EVM With the Plug-N-Play Evaluation Platform 3.3.3 Mute/Mode The TPA711 MSOP EVM is equipped with a mute (shutdown) control input pin. When this input is tied to V , the TPA711 amplifier IC on the module shuts down and assumes an ultra-low power mode. - Page 23 JP6. When JP6 is set to Mute, use the following JP8 settings for the TPA711: To mute the TPA711 MSOP amplifier module when a plug is inserted into the headphone jack, jumper JP8 to Hi (this is the typical setting).
- Page 24 Power Requirements The TPA711 MSOP audio power amplifier evaluation module can operate from any voltage between approximately 2.5 V and 5.5 V; however, the TPA711 amplifier IC on the module is characterized for operation at 3.3 V and 5 V. For...
-
Page 25: Typical Headphone Plug
J10 to the output lines of either the headphone amplifier socket or the power amplifier sockets (Figure 3 – 5). When the TPA711 output signal is routed to J10 by S3, signals output via J10 are returned to platform ground when a plug is inserted (Figure 3 –... -
Page 26: Tpa711 Msop Evm Connected For Stereo Btl Output
Note: The (SE/BTL) EVM pin is pulled to GND through a 20-kΩ resistor on the module. † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB 3-12... -
Page 27: Tpa711 Msop Evm
(active high) U1 † OUT– OUT+ SE/BTL TEXAS Audio INSTRUMENTS Input SLOP214 (Left) TPA711 MSOP EVM † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB Details 3-13... -
Page 28: Tpa711 Msop Evm Parts List
700 mW, mono TPA711DGN PCB1 PCB, TPA711 MSOP EVM † Due to the very small size of the MSOP IC package, the standard part number TPA711 is replaced with the code TIABB NOTE: All items are SMD except as noted. 3-14 Details... - Page 29 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TPA711MSOPEVM...
