JZL102
Leaflet No. 463442
rev01
Read through
ALL
instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jzl102 for more information.
25"
CUSTOMER SERVICES HELP LINE NUMBER:
33lbs
01952 670009
63cm
15kg
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Related Manuals for AVF JZL102
Summary of Contents for AVF JZL102
- Page 1 If you have any questions about this product or issues with installation STOP contact the customer services helpline before returning this product to the store. See jl.avfgroup.com/p/jzl102 for more information. 25" CUSTOMER SERVICES HELP LINE NUMBER: 33lbs 01952 670009 63cm 15kg AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Assembly Overview
Assembly Overview Fit the Mounting Plate Fit the Wall Bracket Attach the TV... - Page 3 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall.
-
Page 4: Tools Recommended
Tools Recommended Stud Finder Ø7mm (17/64") Ø3mm (1/8") Masonry Wood Boxed Parts... -
Page 5: Before You Begin
TV Screws NYLON 2.5mm Before you begin Remove Remove top cover bottom cover Keep top and bottom covers until step 5. - Page 6 Measure the TV fixing holes Width and Height TV Fixing Holes 75 / 100mm 75 / 100mm If X or Y are not equal to 75 or 100mm STOP installation now and contact the customer help line. 100mm 75mm 75mm 100mm...
- Page 7 Fitting the TV Mounting Plate 2.5mm If your TV has an irregular back or if you have any issues fitting to the back of your TV with the screws supplied, please call the customer services helpline 01952 670009 / 0870 0609777...
- Page 10 Assemble the bracket Use your finger and thumb to hold nyloc nut (K) steady while you tighten screw ( ) L NYLON...
- Page 11 Fitting the Top and Bottom Covers Fit the top cover Fit the bottom cover...
- Page 12 Attach the TV IMPORTANT Ensure safety plunger is down Click! Click! To remove TV i. Remove parts G and H ii. Lift safety plunger and pull TV away (Safety plunger can be locked open by turning anti clockwise after lifting) TV levelling and Tilt Levelling Tilt...
