JZL4701
Leaflet No. 464012
rev03
Read through
ALL
instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jzl4701 for more information.
55"
CUSTOMER SERVICES HELP LINE NUMBER:
66lbs
01952 670009
139cm
30kg
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF JZL4701
Summary of Contents for AVF JZL4701
- Page 1 If you have any questions about this product or issues with installation STOP contact the customer services helpline before returning this product to the store. See jl.avfgroup.com/p/jzl4701 for more information. 55" CUSTOMER SERVICES HELP LINE NUMBER: 66lbs 01952 670009 139cm 30kg AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
- Page 2 Assembly Overview Fit the TV Brackets Fit the Wall Bracket Connect the TV Tilt (if required)
- Page 3 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall.
-
Page 4: Tools Recommended
Tools Recommended Stud Finder Ø10mm (25/64") Ø3mm (1/8") Masonry Wood Boxed Parts... - Page 5 TV Screws, Reducers and Spacers...
- Page 6 Measure the TV fixing holes Width and Height TV Fixing Holes 100 - 400mm 100 - 400mm If width X is greater than 400mm or height Y greater than 400mm STOP installation now and contact the customer help line You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and M8.
- Page 7 Preparing the TV Brackets To ensure maximum tilt is possible after installation you will need to ensure that your TV does not clash with the wall. No Clash Clash Bottom Bottom If a clash is observed you have 2 options: Option 1 Move Bracket B closer to the bottom of your TV No Clash...
- Page 8 Fitting the TV Brackets No Spacers Spacer For Tvs with flat/unobstructed back For Tvs with irregular/obstructed back WARNING After completing step 3 you will have fittings left over, please keep for future reference...
- Page 9 Screw diameter dependant If required If required Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 12 Connecting the TV Attaching TV Levelling Adjust tilt tension if required. Equally tighten nuts to suit.
