JNL655
Leaflet No. 463998
rev01
Read through
ALL
instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jnl655 for more information.
80"
CUSTOMER SERVICES HELP LINE NUMBER:
132lbs
01952 670009
203cm
60kg
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF JNL655
Summary of Contents for AVF JNL655
- Page 1 If you have any questions about this product or issues with installation STOP contact the customer services helpline before returning this product to the store. See jl.avfgroup.com/p/jnl655 for more information. 80" CUSTOMER SERVICES HELP LINE NUMBER: 132lbs 01952 670009 203cm 60kg AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Assembly Overview
Do Not remove Do Not remove until step 6 until step 6 Assembly Overview 2 Person Installation Recommended Fit the TV Mounting Plate Fit the Wall Bracket Connect the TV... - Page 3 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall.
-
Page 4: Tools Recommended
Tools Recommended Stud Finder Ø12mm Ø3mm Masonry Wood Boxed Parts... - Page 5 TV Screws, Reducers and Spacers...
- Page 6 Measure the TV fixing holes Width and Height 75, 100, 200, TV Fixing Holes 300, 400, 600mm 75, 100, 200, 300, 400mm If width X is not equal to 75, 100, 200, 300, 400 or 600mm or height Y is not equal to 75, 100, 200, 300, 400mm STOP installation now and contact the customer help line You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and...
- Page 7 Preparing the Front Adaptor Plate...
- Page 8 Preparing the TV Mounting Plate Use the option that fits your TV. Do not fully tighten. OPTION 1 OPTION 2 OPTION 3 OPTION 4 = 75, 100, 200mm = 400mm = 300 or 400mm = 600mm = 75, 100, 200mm = 200mm = 300 or 400mm = 400mm...
- Page 9 OPTION 3 400mm 300mm = fixing position OPTION 4 600mm = fixing position...
- Page 10 Fitting the TV Mounting Plate Before you fully tighten the TV mounting plate please check that the mounting plate holes line up with the fixing holes on the back of your TV. Holes do not line up and Holes line up and no small adjustment is required adjustment is required before you fully tighten...
- Page 11 Screw diameter dependant Fixings shown are valid for options 1,2,3 & 4 and / or and / or and / or and / or Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 14 Fitting the Wall Bracket Covers Connecting the TV Attaching and Locking...
-
Page 15: Cable Management
Cable Management Check all fittings are tight Ensure cables don’t restrict arm movement... - Page 16 Optional Lock Tilt Lateral Shift WOOD STUD ONLY Remove TV Levelling Replace...
