253
(3) Slide the slot bracket out.
7
Install the PCI Express network card.
(1) Align the PCI Express network card to the slot.
(2) Insert the PCI Express network card until it is properly seated
in the slot.
(3) Close the slot cover.
(4) Secure the card with the screw removed earlier.
