  • Page 1 DC-D Series Installation Manual DC-D3212RX-N / DC-D3212X-N Powered by...
  • Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
  • Page 4 IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    • Easy network access via UPnP (Universal Plug and ethernet. Play) function and embedded mDNS (Multicast DNS) You can use the IDIS Discovery program to change protocol network camera settings or the IDIS Solution Suite • Wide dynamic range compensation (True WDR) for...

  • Page 7: Accessories

    Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Guide Pattern Screws (2 ea.) Quick Guide...

  • Page 8: Overview

    Part 1 – Introduction Overview Body Product color and design may vary depending on the DC-D3212X-N model. Dome Cover DC-D3212RX-N Side Cable Access Hole • Side Cable Access Hole For routing cables.
  • Page 9 PoE switch use, refer to the switch manufacturer's operation manual. You can configure, manage, and upgrade this camera and monitor its images from a remote computer over the network. For more information on network connection setup, refer to the IDIS Discovery operation manual.

  • Page 10: Factory Reset

    Remove the dome cover. on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery...

  • Page 11: Inserting A Sd Memory Card

    Part 1 – Introduction Inserting a SD Memory Card Insert a SD memory card into the SD memory card slot with the 'microSD' printed facing upward. Push the SD memory card until it disengages from the slot, and then pull it out. Installation •...

  • Page 12: Closing The Dome Cover

    Part 1 – Introduction Closing the Dome Cover Dimension Attach the dome cover to the bottom cover. Turn the dome cover clockwise to fasten the dome cover. 111.9mm (4.4") Angle Adjustment The lens can be rotated along three axes. Lens Rotation Horizontal Rotation Vertical Rotation •...

  • Page 13: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Power Network Camera Power Monitor Out Network Remote Monitoring DirectIP™ NVR makes it easy to use cameras without extra network configurations.

  • Page 14: With Non Directip™ Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 15: Part 3- Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.

  • Page 16: Specifications

    Part 3- Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/3” CMOS Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type Fixed-focal Focal Length f=4.0mm/f=2.8mm Aperture F2.0/F1.8 Iris Control Fixed Iris Angular Field of View H: 80.3°...
  • Page 17 Part 3- Appendix Network Video Compression H.265(MP), H.264(MP), M-JPEG Bitrate Control H.264 - VBR/CBR H.265 Max. Frame Rate 30fps : 1920 x 1080 (WDR) Supported DirectIP 1920x1080, 1280x720, 704x480, 640x360, 352x240 Resolution Non DirectIP 1920x1080, 1280x720, 704x480, 640x360, 352x240 Multi-Video DirectIP Quadruple Streaming...
  • Page 18 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...

This manual is also suitable for:
