COMPACT ALL-FREEZER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES
AND OPERATING INSTRUCTIONS. KEEP THIS MANUAL IN A SECURE LOCATION.
Write Serial Number (on back of unit) here:
_______________________________
FS22L
Model No.
Instruction Manual
Felix Storch, Inc.
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit FS22L
Summary of Contents for Summit FS22L
- Page 1 COMPACT ALL-FREEZER FS22L Model No. Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. KEEP THIS MANUAL IN A SECURE LOCATION. Felix Storch, Inc. Write Serial Number (on back of unit) here: 770 Garrison Avenue...
-
Page 2: Table Of Contents
Locking the Freezer .................. 8 Reversing the Door Swing of Your Freezer ..........9 Troubleshooting ....................10 Limited Warranty ..................... 11 TECHNICAL INFORMATION Model Number: FS22L Capacity: 1.13 cubic feet Electrical Rating: 115V AC / 60Hz / 1.2A Input Power:... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Before the freezer is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the freezer, follow basic precautions, including the following: ... - Page 4 This unit is not designed to operate in enclosed spaces. When placing your unit, make sure you allow at least 4” of clearance on all sides. Use two or more people to move and install the freezer. Failure to do so can result in back or other injury.
-
Page 5: Location Of Parts
LOCATION OF PARTS INSTALLATION PLACEMENT The freezer should not be placed in direct sunlight or close to heat sources such as oven, grill, radiator, etc. Also avoid locations where the unit will be exposed to moisture or can be easily splashed. ... -
Page 6: Electrical Connection
When installing the unit on a table or countertop, keep the following in mind: Surface (countertop) is flat, level, and strong enough to support the unit once it is fully loaded. Surface is wide enough to accommodate the unit without any overhang. ... -
Page 7: Operation
OPERATION TEMPERATURE ADJUSTMENT The cabinet temperature is controlled by the thermostat at the back of the freezer. Rotate the dial to adjust the cabinet temperature. The setting OFF indicates that the device is turned off. Turning the thermostat clockwise from this setting turns the freezer on automatically. -
Page 8: Normal Phenomena
NORMAL PHENOMENA It is normal that both side panels and the top of the freezer be warm because of the built-in condenser. There may be condensation on the surface of the appliance when it is placed in an area of high humidity or when the weather is hot. -
Page 9: Energy-Saving Tips
MOVING YOUR FREEZER 1. Remove all the food. 2. Securely tape down all loose items inside your freezer. 3. Tape the door shut. 4. Be sure the freezer stays secure in the upright position during transportation. Do not lay it on its side or even incline it more than 45°. Protect the outside of the freezer with a blanket or similar item. -
Page 10: Reversing The Door Swing Of Your Freezer
The unit is delivered to you with the door opening from the left side. Should you desire to reverse the opening direction, follow the diagram and directions below. If you have a problem, call SUMMIT Customer Service at 1-800-932-4267. NOTE: All parts removed must be saved for reinstalling the door. -
Page 11: Troubleshooting
Under these conditions, side-panel heating is normal; heat is being dissipated from inside the cabinet. If your freezer shows other symptoms than those described above, or if you have checked all items listed as the cause and the problem still exists, then call SUMMIT® Customer Service at 1-800-932-4267... -
Page 12: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
