TM
ProStar MPPT
Solar Charging System Controller
Installation, Operation and Maintenance Manual
For the most recent manual revisions, see the e-version at:
www.morningstarcorp.com
www.morningstarcorp.com
MODELS
PS-MPPT-15
PS-MPPT-15M
PS-MPPT-25
PS-MPPT-25M
PS-MPPT-40
MAXIMUM POWER POINT TRACKING
PS-MPPT-40M

Advertisement

Table of Contents
loading

Related Manuals for Morningstar ProStar MPPT TRAKSTAR PS-MPPT-15

Summary of Contents for Morningstar ProStar MPPT TRAKSTAR PS-MPPT-15

  • Page 1 ProStar MPPT Solar Charging System Controller Installation, Operation and Maintenance Manual For the most recent manual revisions, see the e-version at: www.morningstarcorp.com www.morningstarcorp.com MODELS PS-MPPT-15 PS-MPPT-15M PS-MPPT-25 PS-MPPT-25M PS-MPPT-40 MAXIMUM POWER POINT TRACKING PS-MPPT-40M...
  • Page 2 DIMENSIONS [inches (centimeters)] 7.88 (20.0 ) 6.69 (17.0 ) 4.92 ( 13.0) 6.69 ( 17.0) 2.78 ( 7.0 ) SPECIFICATION SUMMARY PS-MPPT-15 PS-MPPT-25 PS-MPPT-40 Nominal Battery 12/24V 12/24V 12/24V Voltage Max. PV Open- 120V 120V 120V Circuit Voltage* 550 / Maximum Operating 210 / 420W 350 / 700W...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1.0 Important Safety Instructions ......1 2.0 General Information ..........10 Overview ...............10 Regulatory Information........11 Versions and Ratings..........13 Features ..............14 Optional Accessories ..........16 3.0 Installation ............18 General Installation Notes ........18 Configuration ............21 Mounting ..............24 Wiring ..............25 4.0 Operation .............35 TrakStar MPPT Technology ........
  • Page 4 4.7.4 Using the Meter Display to Program Charging Set-points, Load Control, Communications, and Advanced Settings............55 4.7.5 Lighting Control / Programming Overview....55 4.7.6 Lighting Programming Using Meter Display.....56 Inspection and Maintenance........57 5.0 Troubleshooting........... LED Fault Indications...........59 Battery Charging and Performance Issues....64 6.0 Warranty and Policies........

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important safety, installation, operating and mantenance instructions for the ProStar MPPT solar controller. The following symbols are used throughout this manual to indicate potentially dangerous conditions or mark important safety instructions: WARNING: Indicates a potentially dangerous condition.
  • Page 6 Safety Information • Read all of the instructions and cautions in the manual before beginning installation. • There are no user serviceable parts inside the ProStar MPPT. Do not disassemble or attempt to repair the controller. WARNING: Risk Of Electrical Shock. NO POWER OR ACCESSORY TERMINALS ARE ELECTRICALLY ISOLATED FROM DC INPUT, AND MAY BE EN- ERGIZED WITH HAZARDOUS SOLAR VOLTAGE.
  • Page 7 • External solaire et la batterie se déconnecte sont néces- saires. • Déconnectez toutes les sources d’alimentation du con- trôleur avant d’installer ou de régler le ProStar MPPT. • Le TriStar MPPT ne contient aucun fusible ou interrupteur. Ne tentez pas de réparer. •...
  • Page 8 Ground Symbol • This charge controller is to be connected to DC circuits only. These DC connections are identified by the symbol below: Direct Current Symbol The ProStar MPPT controller must be installed by a qualified technician in accordance with the electrical regulations of the country of installation.
  • Page 9 • Montez le ProStar MPPT à l’intérieur. Empêchez l’exposition aux éléments et la pénétration d’eau dans le contrôleur. • Installez le MPPT ProStar dans un endroit qui empêche le contact occasionnel. Le dissipateur de chaleur Pro- Star MPPT peut devenir très chaud pendant le fonc- tionnement.
  • Page 10 Le régulateur MPPT ProStar doit être installé par un technicien qualifié conformément aux règlements du pays d'installation électriques. Un moyen de déconnexion de tous les poteaux d'alimentation doit être fourni. Ceux-ci se déconnecte doit être intégrée dans le câblage fixe. Une mise à...
  • Page 11 PRUDENCE: Lorsque le remplacement des piles, utilisez correctement nombre spécifié, tailles, types et les évaluations basées sur conception de système et d'application. CAUTION: Do not open or mutilate batteries. Released electrolyte is harmful to skin, and may be toxic. PRUDENCE: Ne pas ouvrir ou mutiler les piles. L'électrolyte est nocif pour la peau et peut être toxique.
  • Page 12 • Never smoke in the battery area. • If battery acid comes into contact with the skin, wash with soap and water. If the acid contacts the eye, flood with fresh water and get medical attention. • Be sure the battery electrolyte level is correct before starting charging.
  • Page 13 • Lisez attentivement les instructions du fabricant de la batterie avant d'installer / connexion à ou retrait des batteries du ProStar MPPT. • Veillez à ne pas court-circuiter les câbles connectés à la batterie. • Ayez une personne à proximité qui puisse aider en cas d’accident.

  • Page 14: General Information

    • LED indications and push-button or meter key functions • Terminals sized for #2 AWG (35mm ) wire - compliant when used with the optional Morningstar Wire Box, otherwise a maximum of #6 AWG wire. • Includes battery voltage sense terminals •...

  • Page 15: Regulatory Information

    Changes or modifications not expressly approved by Morningstar for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
  • Page 16 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer, or an experienced radio/TV technician for help. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.

  • Page 17: Versions And Ratings

    2.3 Versions and Ratings PS-MPPT-25 • Rated for maximum 25 amps continuous current (battery or load) • Designed for 12 or 24 VDC systems PS-MPPT-25M • Includes metering display • Rated for maximum 25 amps continuous current (battery or load) •...

  • Page 18: Features

    2.4 Features The features of the ProStar MPPT are shown in Figure 2-1 below. An explanation of each feature is provided. Figure 2-1. PS-MPPT Features General Information...
  • Page 19 13 - Battery Sense Terminals Connection points for battery voltage sensing wires 14 - Remote Temperature Sensor Terminals (RTS) Connection points for a Morningstar RTS to remotely monitor battery temperature 15 - Wire Box for ProStar-MPPT Optional accessory to route wiring through knock-outs...

  • Page 20: Optional Accessories

    2.5 Optional Accessories The following accessories are available for purchase separately from your authorized Morningstar dealer: Remote Temperature Sensor (Model: RTS) The RTS measures battery temperature for accurate temper- ature compensation and is recommended when the ambi- ent battery temperature differs from the ambient controller temperature by more than 5º...
  • Page 21 USB Communications Adapter (UMC-1) A modular unit that uses a USB-B plug, usually from a USB A-B computer cable, and an RJ-11 plug to connect with a Morningstar controller's MeterBus port, for monitoring and programming using MSView PC software. PC MeterBus Adapter...

  • Page 22: Installation

    INSTALLATION INSTRUCTIONS 3.1 General Installation Notes • Read through the entire installation section first before beginning installation. • Be very careful when working with batteries. Wear eye protection. Have fresh water available to wash and clean any contact with battery acid. •...
  • Page 23 • Do not install in locations where water can enter the controller. • Loose power connections and /or corroded wires may result in resistive connections that melt wire insulation, burn surrounding materials, or even cause fire. Ensure tight connections and use cable clamps to secure cables and prevent them from swaying in mobile applications.
  • Page 24 • Stranded wires to be connected to the ProStar MPPT terminals should be prepared first with e.g. clamped copper heads, etc. to avoid the possibility of one conductor free out of the connection screw, and possible contact with the metal enclosure. WARNING: Solar and battery fuses or DC breakers are required in the system.

  • Page 25: Configuration

    3.2 Configuration The DIP switch block shown in Figure 3.1 below is used to set the operating parameters for the ProStar MPPT. Figure 3.1. DIP Switch Block to set charging parameters Switch 1: Load / Lighting Mode Switch 1 Normal Lighting Switches 2, 3: System Voltage Three (3) system voltage configurations are available as...
  • Page 26 NOTE: Before connecting the battery, measure the open-circuit voltage. It must be over 10 volts to start the controller. If the system voltage Settings Switches are set to Auto-detect, battery voltage over 15.5V will be detected as a 24V nominal battery, and the unit will charge accordingly.
  • Page 27 Switch 7: Battery Equalization Mode Switch 7 Manual Equalization Auto Equalization Switch 8: Meterbus / MODBUS Settings Mode Switch 8 Meterbus MODBUS ProStar MPPT Operator’s Manual...

  • Page 28: Mounting

    3.3 Mounting Inspect the controller for shipping damage. Mount the ProStar MPPT to a vertical surface (4-#8 stainless steel self-tapping screws are included). Tighten the mounting screws, using care not to crack the plastic case. Do not install directly over an easily combustible surface since the heat sink may get hot under certain operating conditions.

  • Page 29: Wiring

    3.4 Wiring S - S+ S+ S+ S+ To battery (+) and (-) terminals for voltage sensing To load (+) To battery (+) To battery for and (-) and (-) temperature To properly terminals terminals sensing sized array Figure 3-3. Wiring the PS-MPPT REFER TO FIGURE 3.3 WHEN USING THE WIRING INSTRUCTIONS BELOW.
  • Page 30 STEP 1: Check Controller Limitations Verify that the highest temperature compensated solar array open-circuit voltage (Voc), and load current do not exceed the ratings of the ProStar MPPT version being installed. Multiple controllers can be installed in parallel on the same battery bank to achieve greater total charging current.
  • Page 31 the true battery voltage would only be 14.1 volts, if there is a 0.3 volt drop between the controller and battery. Note that the battery sense wires will not power the controller, and the sense wires will not compensate for losses in the power wires between the controller and the battery.
  • Page 32 STEP 3: Remote Temperature Sensor WARNING: Risk of Fire. If no Remote Temperature Sensor (RTS) is connected, use the ProStar MPPT within 3m (10 ft) of the batteries. Internal Temperature Compensation will be used if the RTS is not connected. Use of the RTS is strongly recommended. AVERTISSEMENT: Risque d'incendie.
  • Page 33 CAUTION: The ProStar MPPT will use the local temperature sensor for compensation if the RTS is not used. PRUDENCE: Le TriStar MPPT ne compense pas la température des paramètres de charges si le RTS n’est pas utilisé. NOTE: The RTS cable may be shortened if the full length is not needed.
  • Page 34 Figure 3-4. Ground Symbol WARNING: Risk of Fire DO NOT bond system electrical negative to earth ground at the controller. Per NEC requirements, system negative must be bonded to earth ground through a GFPD at only one point. AVERTISSEMENT : Risque d’incendie NE LIEZ PAS le côté...
  • Page 35 STEP 5: Load Connections Turn the loads off, and connect the load wires to the load terminals. DO NOT CLOSE BREAKER AT THIS TIME. BATTERY (+) BATTERY (-) 30 or 50 Amp Breaker - depending on model 6 in (150 mm) MAX.
  • Page 36 STEP 6: Battery Connections Be sure that DIP switches 2 and 3 are set for 12 or 24V, as described in Section 3.2 NOTE: Before connecting the battery, measure the open-circuit voltage. It must be over 10 volts to start the controller. If the system voltage Settings Switches are set to Auto-detect, battery voltage over 15.5V will be detected as a 24V nominal battery, and the unit will charge accordingly.
  • Page 37 AVERTISSEMENT: Risque de décharge électrique Le réseau PV solaire peut produire des tensions de circuit ouvert supérieures à 120 Vdc à la lumière du soleil. Vérifiez que le coupe-circuit ou l’interrupteur d’entrée solaire a été ouvert (déconnexion) avant d’installer les câbles du système. With the solar disconnect open, connect the solar (PV) array wires to the PS-MPPT solar terminals.
  • Page 38 • there is an overload condition (LEDs blinking R/Y - G) • the load is not connected, not working, or turned off After all connections have been completed, observe the LEDs to make sure the controller is operating normally for system conditions.

  • Page 39: Operation

    OPERATION 4.1 TrakStar MPPT Technology The ProStar MPPT utilizes Morningstar’s TrakStar Maxi- mum Power Point Tracking technology to extract maximum power from the solar module(s). The tracking algorithm is fully automatic and does not require user adjustment. Trakstar technology will track the array maximum power...
  • Page 40 High Voltage Strings and Grid-tie Modules Another benefit of TrakStar MPPT technology is the ability to charge 12 or 24 volt batteries with solar arrays of higher nominal voltages. A 12 volt battery bank can be charged with a 12, 24, 36 or 48V nominal off-grid solar array. Certain grid-tie solar modules may also be used as long as the solar array open circuit voltage (V ) rating will not exceed the...

  • Page 41: Battery Charging Information

    4.2 Battery Charging Information 4-Stage Charging The ProStar MPPT has a 4-stage battery charging algorithm for rapid, efficient, and safe battery charging. Figure 4-2 shows the sequence of stages. BULK NIGHT FLOAT ABSORPTION NIGHT CHARGE TIME Figure 4.2. ProStar MPPT Charging Algorithm Bulk Charge Stage During Bulk charging, the battery is not at 100% state of charge and battery voltage has not yet charged to the Ab-...
  • Page 42 The battery must remain in the Absorption charging stage for a cumulative 120 - 150 minutes, depending on battery type, before transition to the Float stage will occur. However, Absorption time will be extended by 30 minutes if the battery discharges below 12.50 volts (12V system) the previous night.
  • Page 43 Equalization Stage WARNING: Risk of Explosion Equalizing vented batteries produces explosive gases. The battery bank must be properly ventilated. CAUTION: Equipment Damage Equalization increases the battery voltage to levels that may damage sensitive DC loads. Verify all system loads are rated for the temperature compensated Equalize voltage before beginning an Equalization charge.
  • Page 44 battery voltage above the standard absorption voltage so that the electrolyte gases. The green SOC LED will blink rapidly two (2) times per second during equalization charging. The duration of the equalize charge is determined by the selected battery type. See table 4-1 in this section for more details.
  • Page 45 When to Equalize? The ideal frequency of equalizations depends on the battery type (lead-calcium, lead-antimony, etc.), the depth of discharging, battery age, temperature, and other factors. One very broad guide is to equalize flooded batteries every 1 to 3 months or every 5 to 10 deep discharges. Some batteries, such as the L-16 group, will need more frequent equalizations.
  • Page 46 the “boost” cycle for sealed cells can be disabled by setting the equalize setting switch to manual, if required. Battery Charge Settings Preset ProStar MPPT battery charging options are shown in tables 4-1 and 4-2 below. All voltage settings listed are for nominal 12 Volt batteries.
  • Page 47 The ProStar MPPT provides seven (7) standard battery charging settings that are selected with the settings switches (see Table 4.1 above). These standard charging settings are suitable for lead-acid batteries ranging from sealed (gel, AGM, maintenance-free) to Flooded and L-16 cells. In addition, an eighth charging setting provides for custom set-points using MSView PC software.
  • Page 48 Float Time-out Sub- Bulk Absorption Float Bulk Absorption Float Float V 60 mins. below Float time (hrs) 1:00 2:00 3:00 4:00 5:00 6:00 Figure 4-4. Float Exit Time-out Charging Profile After entering Float stage, the controller will only exit Float if the battery voltage remains below Float voltage for 60 cumulative minutes.
  • Page 49 Float Cancel Voltage Figure 4.5. Float Cancellation Charging Profile If the battery bank discharges below 12.30 volts (24.60 volts @ 24 V) the previous night, Float charging stage will be cancelled for the next charge cycle. Figure 4-5 above, illustrates this concept. At 0:00 hrs (dawn), battery voltage is below the Float Cancel threshold voltage.
  • Page 50 Equalize Time-out Figure 4.6. Equalize Time-out Charging Profile The charging profile in figure 4-6 above, shows an Equalize Timeout event. The timeout timer begins as soon as battery voltage exceeds the Absorption voltage setpoint. If there is insufficient charging current or system loads are too large, the battery voltage may not reach the Equalize setpoint.

  • Page 51: Load Control Information

    4.3 Load Control Information The primary purpose of the load control function is to disconnect system loads when the battery has discharged to a low state of charge and reconnect system loads when the battery is sufficiently recharged. System loads may be lights, pumps, motors, DC appliances, and other electronic devices.
  • Page 52 The amount of time between a green SOC indication and load disconnect will depend on many factors including: • rate of discharge (amount of load draw) • capacity of the battery • health of the battery • LVD set-point If the battery discharges to the LVD set-point the load will disconnect and a solid red Battery Status LED indication will be displayed.

  • Page 53: Led Indications

    4.4 LED Indications KEY: G = green G - Y - R = flashing sequencially Y = yellow G / Y = flashing together R = red G / Y - R = G and Y flashing together, alternating with R flash 4.4.1.

  • Page 54: State-Of-Charge Leds

    NOTES: 1) R flashing is generally a user addressable fault / error 2) R charging status LED ON with heartbeat blink OFF every 5 secs is a critical fault that generally requires service. See, "Solid Charging Status LED with Self-test (R-Y-G) SOC Faults", in Section 5.1.

  • Page 55: Alarms

    Lighting Control Mode (DIP 1 ON) • A quick press and release will clear any faults or reminders that are present. A second quick press will then conduct a lighting test. If no faults or reminders are present, the initial press will conduct a lighting test. A lighting test is used to verify correct wiring in the load circuit and/or verify the lighting components are operational.
  • Page 56 Heatsink Temperature Sensor Open / Shorted The heatsink temperature sensor is damaged. Return the controller to an authorized Morningstar dealer for service. Battery Sense Out of Range / Disconnected A battery sense wire is disconnected. Inspect the battery sense connections.

  • Page 57: Custom Settings

    4.7 Custom Settings 4.7.1 Programming with the Meter Display The ProStar MPPT is available in metered and non-metered versions. The metered model allows: • Custom programming, including lighting programs, directly from the unit. • Extensive settings adjustment and information as shown partially in Figure 4-7 below: Display Screens and Programming Models:...

  • Page 58: Programming In Msview

    4.7.2 Programming in MSView Beyond the preset DIP switch options, the Prostar MPPT's charging profile and all other settings are customizable using MSView PC software available at: www.morningstarcorp.com WARNING: Risk Of Electrical Shock Hazardous voltage is present at the Meterbus communications port.

  • Page 59: Meter Display Operation

    4.7.3 Meter Display Operation 4.7.3.1 Directional Key Use and Operation / Navigating the Meter Map The ProStar MPPT's meter map consists of two main axes: The horizontal top level daily monitoring screens, and the vertical Main Menu stacked screens. The four lighted triangular directional control keys allow movement to reach any desired point on the meter map.

  • Page 60: Lighting Programming Using Meter Display

    With DIP switch 1 ON (up), a dusk-dawn lighting program is enabled, if lighting timing hasn't been programmed in MSView or using the meter; with DIP 1, 4, 5, 6 ON, and the unit programmed, custom timing will be in effect. With DIP 1 OFF (down), all lighting control functions are disabled.

  • Page 61: Inspection And Maintenance

    4.8 Inspection and Maintenance Table 4-6 below lists the recommended maintenance schedule to keep your ProStar MPPT performing optimally. WARNING: RISK OF ELECTRICAL SHOCK. NO POWER OR ACCESSORY TERMINALS ARE ELEC- TRICALLY ISOLATED FROM DC INPUT, AND MAY BE ENER- GIZED WITH HAZARDOUS SOLAR VOLTAGE.
  • Page 62 Schedule Maintenance Items Re-tighten power terminal 2 weeks after installation connections to specified torque values. Re-tighten power terminal 3 months after installation connections to specified torque values. Inspect the battery bank. Look for cracked or bulging cases, and corroded terminals. For wet cell (flooded type) Monthly or After Each batteries, make sure the...

  • Page 63: Troubleshooting

    TROUBLESHOOTING WARNING: RISK OF ELECTRICAL SHOCK. NO POWER OR ACCESSORY TERMINALS ARE ELEC- TRICALLY ISOLATED FROM DC INPUT, AND MAY BE ENER- GIZED WITH HAZARDOUS SOLAR VOLTAGE. UNDER CERTAIN FAULT CONDITIONS, BATTERY COULD BECOME OVER- CHARGED. TEST BETWEEN ALL TERMINALS AND GROUND BEFORE TOUCHING.
  • Page 64 disconnected. A small overload could take a few minutes to disconnect. The ProStar MPPT will attempt to reconnect the load two (2) times. Each attempt is approximately 10 seconds apart. If the overload remains after two (2) attempts, the load will remain disconnected until power is removed and re-applied.
  • Page 65 can be used to determine if the RTS is working properly. Battery Sense Cables Issue Error status LED: Flashing red. Battery status LEDs: R/Y - G/Y sequencing. If a fault in the battery sense connection (such as a short-circuit, open circuit or loose terminal) occurs after the battery sense has been working, the LEDs will indicate a failure.
  • Page 66 Battery Over-Current Error status LED: Flashing red. Battery status LEDs: R/Y-G sequencing. While rare, if battery charging current exceeds approximately 130% of the controller’s output current rating, this fault can occur. The fault is generally related to fast, large battery voltage transients (connecting a very heavy or capacitive load like an inverter) that are faster than the controller can regulate and it shuts off to protect the circuitry.
  • Page 67 SOLID CHARGING STATUS LED with SELF-TEST (R-Y-G) SOC FAULTS Verify that nothing has been mis-wired. If not, the error is likely critical. Contact an authorized Morningstar dealer for support. Fault Charging Status LED Battery SOC LEDs PV FET Short Solid red...

  • Page 68: Battery Charging And Performance Issues

    If the voltage on the battery terminals of the controller is between 10 and 35 vdc, and no LEDs are lit, contact your authorized Morningstar dealer for service. If no voltage is measured, check wiring connections, fuses, and breakers.

  • Page 69: Warranty And Policies

    TWO (2) years from the date of shipment to the original end user. Morningstar will, at its option, repair or replace any such defective products. WARRANTY EXCLUSIONS AND LIMITATIONS: This warranty does not apply under the following conditions: ♦...
  • Page 70 - including the String Calculator array design tool (at www. morningstarcorp.com) - are available to assist in these areas. Morningstar can help refer customers to a nearby autho- rized distributor, dealer, or installer if assistance is required in designing a renewable energy system that best suits your specific needs.
  • Page 71 MORNINGSTAR TECHNICAL SUPPORT POLICIES (Cont.) ♦ Please visit the Tech Support section at www.morningstarcorp.com for any documentation or specification needs before requesting support. The site also offers an array sizing tool (String Selector), product comparison tool (Product Comparator) and articles on solar charging technologies and other design considerations.
  • Page 72 Morningstar Warranty Dept. 5. If instructed by Morningstar, after warranty replacement shipment has been received, return of failed unit(s) is required before further warranty replacements can be considered for the original or future cases.

  • Page 73: Technical Specifications

    TECHNICAL SPECIFICATIONS PS-MPPT-15 PS-MPPT-25 PS-MPPT-40 PS-MPPT-15M PS-MPPT-25M PS-MPPT-40M Electrical: Nominal Battery Voltage 12 volts or 24 volts (all) Battery Voltage Range 10-35 volts (all) Voltage Accuracy 0.1% +/- 50mV (all) Max. Battery Current 15 amps 25 amps 40 amps Max. PV Open-Circuit Voltage 120 volts (all) Load Current Rating 25 amps...
  • Page 74 Battery Charging Set-points (@ 25°C) [multiply voltages by (2) for 24 volt systems] Absorp. Float Equalize Absorp. Equalize Equalize Equalize Switch Battery Stage Stage Stage Time Time Timeout Interval Settings Type (volts) (volts) (volts) (mins) (mins) (mins) (days) 4-5-6 off-off-off 1 - Sealed* 14.00 13.70 off-off-on 2 - Sealed*...
  • Page 75 Data & Communications: Communication Port MeterBus Comm. Protocols Morningstar MeterBus; MODBUS Datalogging 6-8 months, daily records PC Software MSView Digital Meter: Resolution 128 x 64 Viewing Area 70mm x 40mm Display Color blue on white Backlight Operating Temperature -20C to +70C...

  • Page 76: Appendix A - Efficiency

    APPENDIX A - Efficiency Graphs Appendices...
  • Page 77 ProStar MPPT Operator’s Manual...

  • Page 78: Appendix B - De-Rating Graphs

    APPENDIX B - De-rating Graphs Battery Current vs. Array Voltage (Vmp) Array Voltage (Volts) Battery Current vs. Ambient Temperature 100Vmp 80Vmp 60Vmp 40Vmp 20Vmp 25 30 32 33 34 35 36 37 38 39 40 41 42 43 45 46 47 48 49 50 51 52 53 54 55 56 57 60 61 Ambient Temperature (degrees C)

  • Page 79: Appendix C - Wire Sizing Charts

    APPENDIX C - Wire Sizing Charts 2% Voltage Drop Charts for 75°C Stranded Copper Wire 1-Way Wire Distance (feet), 12 Volt System Wire Size (AWG) 2/0 * 33.6 38.4 44.8 53.8 67.2 89.6 134.4 268.9 26.6 30.4 35.5 42.6 53.3 71.0 1/0 * 106.6 213.1...
  • Page 80 2% Voltage Drop Charts for 75°C Solid Copper Wire 1-Way Wire Distance (feet), 12 Volt System Wire Size (AWG) 2/0 * 41.7 47.7 55.6 66.7 83.4 111.2 166.8 333.6 1/0 * 33.1 37.8 44.1 52.9 66.1 88.2 132.3 264.6 20.8 23.8 27.7 33.3...
  • Page 81 *Wires sizes larger than 2 AWG (35 mm ) must be terminated at a splicer block located outside of the ProStar MPPT wiring box. Use 2 AWG (35 mm ) or smaller wire to connect to the ProStar MPPT to the splicer block.
  • Page 82 2% Voltage Drop Charts for 90°C Stranded Copper Wire 1-Way Wire Distance (feet), 12 Volt System Wire Size (AWG) 2/0 * 33.6 38.4 44.8 53.8 67.2 89.6 134.4 268.9 1/0 * 26.6 30.4 35.5 42.6 53.3 71.0 106.6 213.1 16.8 19.1 22.3 26.8...
  • Page 83 2% Voltage Drop Charts for 90°C Solid Copper Wire 1-Way Wire Distance (feet), 12 Volt System Wire Size (AWG) 2/0 * 41.7 47.7 55.6 66.7 83.4 111.2 166.8 333.6 1/0 * 33.1 37.8 44.1 52.9 66.1 88.2 132.3 264.6 20.8 23.8 27.7 33.3...
  • Page 84 *Wires sizes larger than 2 AWG (35 mm ) must be terminated at a splicer block located outside of the ProStar MPPT wiring box. Use 2 AWG (35 mm ) or smaller wire to connect to the ProStar MPPT to the splicer block.

  • Page 85: Certifications

    • Immunity: EN 61000-4-3: 2006 EN 61000- 4-6: 2009 • Emissions: CISPR 22: 2008 ProStar MPPT , MeterBus are trademarks of Morningstar Corporation MODBUS and MODBUS TCP/IP are trademarks of Modbus IDA. www.modbus-ida.org © 2015 Morningstar Corporation. All rights reserved. MS-001537 v1.2 Certifications...
