I N S T A L L A T I O N G U I D E
SB-GM-SLVCTR2/10W3v3
SKU# 94350 - 94353
2007 - 2013 Silverado, Sierra, Avalanche, Suburban, Tahoe, Yukon & Yukon XL
with Front Row 40/20/40 Split Bench Seating
Thank you for choosing a JL Audio Stealthbox ® for your automotive sound system. With proper installation, your new vehicle-
specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
professionals employed by your dealer have the necessary tools and experience to disassemble and reassemble your vehicle
properly. Also, keep in mind that your warranty coverage extends to 2 years if your system is installed or approved by your
authorized JL Audio dealer. If you prefer to perform your own installation, please read this installation guide completely
before beginning the process.
for the
installed by your authorized JL Audio dealer. The installation
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-GM-SLVCTR2/10W3v3_INSTR_SKU#011248
INSTALLATION
D I F F I C U L T Y :
2
OUT
OF
ESTIMATED TIME:
1-2 HOURS
S T E P 1
Remove any contents from the front seat area.
Flip the center seat back / storage bin in the up position.
S T E P 2
Move both front seats all the way forward.
From the passenger side of the vehicle, look to the side of
the center seat back / storage bin.
Remove the black plastic push clip.
Remove the plastic trim.
S T E P 3
From the driver's side of the vehicle, look to the side of the
center seat back / storage bin.
Remove the bolt and plastic trim.
Continued on Next Page
