JL Audio Stealthbox SB-VW-GTI/10TW3 Installation Manual

I N S T A L L A T I O N G U I D E
for the
SB-VW-GTI/10TW3
SKU# 94572
2006 - 2013 Volkswagen GTI MkV, Rabbit & R32
Thank you for choosing a JL Audio Stealthbox for your automotive sound system. With proper installation, your new
®
vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
installation professionals employed by your dealer have the necessary tools and experience to disassemble and
reassemble your vehicle properly. If you prefer to perform your own installation, please read this installation guide
completely before beginning the process.
installed by your authorized JL Audio dealer. The
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
13 1/2 inches
6 inches
SB-VW-GTI/10TW3_INSTR_SKU#011250
INSTALLATION
D I F F I C U L T Y :
2
OUT
OF
ESTIMATED TIME:
1 HOUR
S T E P 1
Remove any contents from the cargo area.
S T E P 2
Place the supplied wax square onto the driver's side rear
cargo panel.
S T E P 3
Thread the supplied socket cup screw into the rear of the
Stealthbox®.
Continued on Next Page
5
