JL Audio Stealthbox SB-GM-SLVCTR2/10W3v3 Installation Manual

I N S T A L L A T I O N G U I D E
SB-GM-SLVCTR2/10W3v3 SB-GM-SLVCTR2/10W3v3
2007 - Up Silverado, Sierra, Avalanche, Suburban, Tahoe, Yukon & Yukon XL 2007 - Up Silverado, Sierra, Avalanche, Suburban, Tahoe, Yukon & Yukon XL
with Front Row 40/20/40 Split Bench Seating with Front Row 40/20/40 Split Bench Seating
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 2 years if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
for the
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-GM-SLVCTR2/10W3v3_INSTR_SKU#011248 SB-GM-SLVCTR2/10W3v3_INSTR_SKU#011248
INSTALLATION
D I F F I C U L T Y :
2
ESTIMATED TIME:
1-2 HOURS 1-2 HOURS
S T E P 1
Remove any contents from the front seat area.
Flip the center seat back / storage bin in the up position.
S T E P 2
Move both front seats all the way forward.
From the passenger side of the vehicle, look to the side of
the center seat back / storage bin.
Remove the black plastic push clip.
Remove the plastic trim.
S T E P 3
From the driver's side of the vehicle, look to the side of the
center seat back / storage bin.
Remove the bolt and plastic trim.
Continued on Next Page
OUT
OF 5
