I N S T A L L A T I O N G U I D E
for the
SB-GM-TAHOCNSL/10W1v3
SKU# 94278
2007 - 2013 Chevrolet / GMC Full-Size SUV's & Trucks
Suburban, Tahoe, Yukon/ XL, Yukon Denali/ XL Denali, Avalanche,
Silverado, & Sierra/Denali
Thank you for choosing a JL Audio Stealthbox
proper installation, your new vehicle-specific enclosed subwoofer system will deliver
years of listening pleasure.
We strongly recommend that you have your new Stealthbox
authorized JL Audio dealer. The installation professionals employed by your dealer have
the necessary tools and experience to disassemble and reassemble your vehicle properly.
Also, keep in mind that your warranty coverage extends to 1 year if your system is
installed or approved by your authorized JL Audio dealer. If you prefer to perform your
own installation, please read this installation guide completely
before beginning the process.
for your automotive sound system. With
®
installed by your
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-GM-TAHOSCNSL/10W1v3_INSTR_SKU#011220
INSTALLATION
D I F F I C U L T Y :
3
OUT
OF
ESTIMATED TIME:
2-3 HOURS
S T E P 1
Using masking tape or similar, mark where the bottom
edge of the front center console meets the carpet on the
driver's side.
S T E P 2
Using masking tape or similar, mark where the bottom
edge of the front center console meets the carpet on the
passenger's side.
S T E P 3
Open the storage lid of the center console. Remove the four
exposed screws.
Continued on Next Page
